0.12mm Small Rotary Airlock Valve 11KW Vacuum Suction Conveying System

China Manufacturer Rotary Airlock Valve For Vacuum Suction Conveying System

Product Introduction

The working thoery of the rotary airlock valve is to adopt the principle of
rotating the impeller and adopt flange connection, which is installed at the
discharge port with pressure difference to ensure that the air pressure in
the conveying pipe does not leak. While feeding continuously and uniformly,
the air circuit is blocked to ensure the use of system. The electric air
lock valve relies on the rotating impeller to transport materials, and at
the same time plays a sealing role, preventing air from sucking in the
outlet during the pneumatic conveying process, and ensuring safe conveying
and collecting of materials.

Dimension Display

0.12mm Small Rotary Airlock Valve 11KW Vacuum Suction Conveying System 0



Type

External dimension Inlet Outlet Install size Shaft
A B H E F D1 D2 e f
h g m D d k
TGFY-5L 410 300 435 250 170 Φ222 Φ152 180 150
160 220 130 Φ200 Φ35 50
TGFY-7L 420 310 435 260 180 Φ250 Φ162 182 160
160 230 140 Φ220 Φ35 50
TFGY-9L 470 310 435 260 230 Φ270 Φ192 182 210
160 230 190 Φ240 Φ40 50
TGFY-12L 520 370 530 320 238 Φ288 Φ208 240
218 190 290 200 Φ260 Φ40 50
TGFY-16L 570 370 530 320 280 Φ330 Φ250 240
260 190 290 240 Φ300 Φ40
0.12mm Small Rotary Airlock Valve 11KW Vacuum Suction Conveying System 1

Main Features of Rotary Airlock Valve :

Highly economical

Broad range of
application

Low energy consumption

Excellent sanitation

0.12mm Small Rotary Airlock Valve 11KW Vacuum Suction Conveying System 2

Application

0.12mm Small Rotary Airlock Valve 11KW Vacuum Suction Conveying System 3

Handling Material

With small size, elegant appearance, compact structure, convenient operation
etc, it is widely used in grain, food, feed, grease, chemicals, electric
power, port and wharf, storage and transportation industries etc.

For different sizes, shapes handling material with different charateristics,
we have professional plans and solutions to deal with them in pneumatic
conveying system.

0.12mm Small Rotary Airlock Valve 11KW Vacuum Suction Conveying System 4

Processing Procedure

For every production step our workers are carefully finished. QC department
is strictly following the quality standard by 100% inspection for all the
products. Cheegers never stop studying,researching and developing new
designs on rotary valves. Each year, we will launch new designs which suit
different application conditions.

0.12mm Small Rotary Airlock Valve 11KW Vacuum Suction Conveying System 5

Certificate

There are 63 years of producing and design , any kind of OEM and
customization are acceptable!
We can design and build flour mill ,rice mill and all pneumatic hanlding
system !
Provide solutions to all pneumatic handling system !
We help you choose the proper model!

0.12mm Small Rotary Airlock Valve 11KW Vacuum Suction Conveying System 6

Click to Enlarge
