1.5 Inch 4000psi Brass Internal Dry Pressure Gauge With Front Flange

1.5 inch 4000psi high pressure with back connection and front flange
installation style , stainless steel case, brass internal and connection.

Specifications of 1.5 Inch 4000psi Brass Internal Dry Pressure Gauge With
Front Flange

Dial 1.5”,2”,2.5”,3”,4″,6”,8",10" ,
(40mm,50mm,63mm,75mm,100mm,150mm,200mm,250mm)< , br>Scale ranges -1/600bar
Accuracy class 1.6%(≤63mm);1.0%(>63mm)
Process connection 1⁄4″(63mm),1⁄2″(100 mm or above )NPT or BSP or BSPT
Bourdon tube Brass
Wetted parts/socket Brass
Movement Brass
Pointer Aluminum, micrometer adjustable available
Welding Sn Welding; Silver alloy Welding for high pressure series
Case material Stainless steel 304,DIN bayonet bezel or crimped ring
Window(lens) Tempered glass, pc or safety glass
Fill Glycerin or silicone
IP class IP 65

Product Pictures:

Dimension:
Dimension of 1.5 Inch 4000psi Brass Internal Dry Pressure Gauge With Front
Flange

GC gauge is a professional pressure gauge company, we provide front flange
pressure gauge, pressure gauge 4000 psi, 4000 psi gauge, 4000 psi pressure
gauge, solid front pressure gauge, fluid pressure gauge and etc. Want to know
more? Contact us now.

Minimum Order: 1 sets

1.5 Inch 4000psi Brass Internal Dry Pressure Gauge With Front Flange
