1 inch - 6 inch Steel Forged Grinding Steel Balls For Gold Mine Cooper Mine

Grinding Steel Balls supply 1-6"forged grinding balls for gold mine,cooper mine

Products introduction

Forged steel ball is divided into carbon grinding steel ball, manganese
grinding steel ball and special grinding steel ball. Forged steel ball is one
of our advantage products. Diameter 20-70mm and 80-150mm steel ball are
produced respectively by advanced automatic hot rolling and hot forging steel
ball production line. Huafu grinding balls with uniform hardness in a high
efficiency due to its advanced quenching technology. In advanced, these
grinding balls feature high accurate dimensions, rounded geometry shape, high
hardness and good mechanical properties, wear - resistance, no deformation, no
breakage.

Manganese steel grinding ball I

Manganese steel grinding ball I is popular in Korea, Japan and North Korea,
impact value is more than 12J/CM^2, manganese content is about 0.6-1.0%. This
is the cheapest one in the manganese grinding balls. The performance as follow:

Chemical Composition

C(%) Si(%) Mn(%) Cr(%) Cu(%) Mo(%) P(%) S(%)
0.48-0.56 0.17-0.37 0.6-1.0 ≤0.25 ≤0.25 ≤0.3 ≤0.035 ≤0.035
Size 20-150mm(0.8inch-6inch)

Hardness

Serious Hardness
Standard Hardness 50-55HRC
High Hardness 55-60HRC
Impact Value ≥12J/CM^2
Balls Number ≥12000times
Microstructure M+C(C-Carbide M-Martensite )

1 inch - 6 inch Steel Forged Grinding Steel Balls For Gold Mine Cooper Mine 01
inch - 6 inch Steel Forged Grinding Steel Balls For Gold Mine Cooper Mine 1

Manganese steel grinding ball II

Manganese steel grinding ball II with high hardness and corrosion resistance
specialty. Mainly used in wet ball mill in mines and quartz sand factories.Has
been exported to Pure, Mexico, Spain, India, Australia and South Africa. The
specific performance as follow:

Chemical Composition

C(%) Si(%) Mn(%) Cr(%) Cu(%) Mo(%) P(%) S(%)
0.57-0.65 0.17-0.37 0.7-1.0 ≤0.25 ≤0.25 ≤0.3 ≤0.035 ≤0.035
Size 20-150mm(0.8inch-6inch)

Hardness

Serious Hardness
Standard Hardness 53-58HRC
High Hardness 55-60HRC
Impact Value ≥15J/CM^2
Balls Number ≥15000times
Microstructure M+C(C-Carbide M-Martensite )

Manganese steel grinding ball III

Manganese steel grinding ball III with high manganese content, impact value is
more than 15J/CM^2, less wearing. Well exported all over the world. Performance
as follow:

Chemical Composition

C(%) Si(%) Mn(%) Cr(%) Cu(%) Mo(%) P(%) S(%)
0.62-0.70 0.17-0.37 0.9-1.0 ≤0.25 ≤0.25 ≤0.3 ≤0.035 ≤0.035
Size 20-150mm(0.8inch-6inch)

Hardness

Serious Hardness
Standard Hardness 55-60HRC
High Hardness 58-63HRC
Impact Value ≥15J/CM^2
Balls Number ≥15000times
Microstructure M+C(C-Carbide M-Martensite )

Special steel grinding ball I

This grinding ball is widely used all over the world. High volume hardness and
less wearing. Quality is well accepted by the customers. Please kindly check
the following detailed performance.

Chemical Composition

C(%) Si(%) Mn(%) Cr(%) Cu(%) Mo(%) P(%) S(%)
0.72-0.80 0.17-0.37 0.8-0.9 0.5-0.6 ≤0.25 ≤0.3 ≤0.035 ≤0.035
Size 20-150mm(0.8inch-6inch)

Hardness

Serious Hardness
Standard Hardness 58-63HRC
High Hardness 62-65HRC
Impact Value ≥15J/CM^2
Balls Number ≥15000times
Microstructure M+C(C-Carbide M-Martensite )

Special steel grinding ball II

This grinding steel ball is one new type steel ball, good toughness and no
breakage. It’s the new favorite in the users. Performance as follow:

Chemical Composition

C(%) Si(%) Mn(%) Cr(%) Cu(%) Mo(%) P(%) S(%)
0.58-0.65 1.60-1.90 0.65-0.80 0.70-0.90 ≤0.25 ≤0.3
≤0.035 ≤0.035
Size 20-150mm(0.8inch-6inch)

Hardness

Serious Hardness
Standard Hardness 58-63HRC
High Hardness 62-65HRC
Impact Value ≥18J/CM^2
Balls Number ≥18000times
Microstructure M+C(C-Carbide M-Martensite )

Other customized material

Series/Element C(%) Si(%) Mn(%) Cr(%) Cu(%) Mo(%) P(%) S(%)
80# 0.77-0.85 0.17-0.37 0.50-0.80 0-0.25 0-0.25 0-0.30
0-0.035 0-0.035
40Mn 0.37-0.44 0.17-0.37 0.70-1.0 0-0.25 0-0.25 0-0.30
0-0.035 0-0.035
40Mn2 0.37-0.44 0.17-0.37 1.40-1.80 0-0.25 0-0.25 0-0.30
0-0.035 0-0.035
70Mn 0.65-0.75 0.17-0.37 0.90-1.20 0-0.25 0-0.25 0-0.30
0-0.035 0-0.035
70Mn2 0.65-0.75 0.20-0.45 1.4-1.8 0-0.25 0-0.25 0-0.30 0-0.035
0-0.035
40Cr 0.37-0.45 0.17-0.37 0.50-0.8 0.80-1.1 0-0.25
0-0.30 0-0.035 0-0.035
70Cr2 0.65-0.75 0.20-0.30 0.75-0.90 0.55-0.70 0-0.25
0-0.30 0-0.030 0-0.030
B1 0.52-0.65 0.17-0.37 0.60-1.2 0-0.25 0-0.25 0-0.30
0-0.035 0-0.035
B2B 0.58-0.65 0.17-0.37 0.90-1.0 0.60-0.65 0-0.25
0-0.30 0-0.035 0-0.035
B4 0.60-0.65 1.60-1.70 0.70-0.80 0.70-0.80 0-0.25
0-0.30 0-0.035 0-0.035
B-6 0.75-0.85 0.2-0.40 0.90-1.0 0.85-0.95 0-0.25
0.06-0.13 0-0.035 02-0.035
B-6A 0.82-0.95 0.20-0.40 0.92-1.02 0.80-0.95 0-0.25
0.06-0.10 0-0.035 0-0.035
B-7 0.35-0.40 0.17-0.37 0.70-0.80 0.90-1.0 0-0.25
0-0.30 0-0.035 0-0.035
BV 1-1.06 0.17-0.37 0.9-1.0 0.55-0.65 0-0.25 0-0.30 0-0.035
0-0.035
GCr15 0.95-1.05 0.15-0.35 0.20-0.40 1.30-1.65 0-0.25
0-0.10 0-0.027 0-0.20
16Mn 0.13-0.19 0.2-0.6 1.2-1.6 0-0.30 0-0.25 --- 0-0.03 0-0.03
