3D Laser Marking Systems Supports Flight Marking Function For IPG Laser Sou

3D Laser Marker Systems Supports Flight Marking Function For IPG Laser Source





Brand Name: BJJCZ
Model Number: DLC2-M4-3D
Place of Origin: China


Minimum Order Quantity: 1pcs
Price: negotiation
Payment Terms: T/T or western Union
Supply Ability: 3,000pcs per month
Delivery Time: 3-5 working days after received your payment
Packaging Details: Packed in carton firstly,and then reinforced with
wooden case for outer packing


Description:



Warranty: 1 years

Place of Origin: China

Applicable Industries:

Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery
Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail,
Food Shop, Printing Shops, Construction works , Energy & Mining, Food &
Beverage Shops, Advertising Company

Used for: Fiber Laser Marking Machine

Input Power: DC24V

Support Software: Ezcad

Interface Port: RS232

DLC2-M4-2D: Dynamic focus, large format marking

DLC2-M4-3D: Support 3D marking



Features:

The DLC2 control board and EZCAD3 software can perform real-time synchronous
control of 2D/3D scanning galvanometer and laser. The main features of the
board are as follows:

(1) Support enhanced version of the XY2-100 data protocol (X, Y, Z triaxial
galvanometer)

(2) Supports fiber, CO2, QCW, SPI, UV, YAG and other lasers through the laser
expansion card

(3) Support 10 input and 8 output ports

(4) 12V power supply, minimum current requirement 3A

(5) Support flight marking function

(6) Support offline marking function

(7) Support 16Bit/18Bit galvanometer, which can be customized according to the
actual galvanometer protocol

The board interface is as follows:



The board has two LED indicators. After the board is powered on, the green
light is always on. The red light is on when the laser light is controlled
during the marking process.

Interface function:

CON1: power interface, 2P green terminal socket;

CON2: laser interface, support all lasers, DB25 socket (female);

CON3: galvanometer interface, support enhanced XY2-100 data protocol, can drive
2D/3D galvanometer, DB15 socket;

CON5: IO interface for flight marking interface, input and output digital
signals, DB37 socket



Applications:



Scanner Type Galvo With XY2-100 Interface Support 16bit/18bit Galvo
Output Signal 8 output
Input Signal 10 input
Communication Interface USB 2.0
Operation System Win 7/8/10 64bit
Software EZCAD3
Support Laser Source CO2,Fiber,UV,SPI,QCW,YAG
Extended axis 4 axis
