400Gbps QSFP-DD DR4+
Optech’s 400G QSFP-DD Transceivers includes QSFP-DD SR8, QSFP-DD LR4 and
The 400G QSFP-DD Transceiver follows the same port densities system as the
QSFP and QSFP28, but the QSFP-DD will support eight lanes instead of four
lanes for the QSFP and QSFP28, which double the density.
Each of the eight lanes will operate a data rate up to 50Gb/s providing a
400Gb/s data speed and increasing the capacity of the QSFP28 by four. The
400G QSFP-DD MSA published that the size of the optical transceivers
enables to put 36 ports in one switch slot, accumulating 14.4 Tbp/s in one
* QSFP-DD MSA compliant
* Parallel 4 Optical Lanes
* 100G Lambda MSA 400G-FR Specification compliant
* Up to 2km transmission on single mode fiber (SMF) with FEC
* Operating case temperature: 0 to 70°C
* 8x53.125Gb/s electrical interface (400GAUI-8)
* Data Rate 106.25Gbps (PAM4) per channel.
* Maximum power consumption 12W
* MPO-12 connector
* RoHS compliant
* 400G Ethernet
* Infiniband interconnects
* Datacenter Enterprise networking
Minimum Order: 50 pieces
