5 to 1000MHz 4 Way Power Divider

Part number:5o337240051000SK
Frequency Range:5~1000MHz
Isolation:20dB
VSWR Input Max:1.4
VSWR Output Max:1.25
Insertion Loss:1.8(Split 6dB)
Phase Unbalance:±6degree
Amplitude Unbalance:±1.0dB
Connector Type:SMA-K
Dimension:72*40*12mm

Applicat , ion
Wireless communication system.
Radar and satellite systems.
Testing and measuring equipment.
Other special applications: harmonic suppression, electronic countermeasure,
etc.
It supports a one-year standard warranty.

5o.com Inc. is a modern high-tech enterprise specializing in passive RF and
microwave components, integrating R&D, production, and sales. The company
focuses on technological innovation as its core and relies on technology
leadership.
The company's main products: Microwave RF isolators, circulators, coaxial
terminations, coaxial attenuators, power splitters/dividers, waveguide to
coaxial adapters, directional couplers, RF filters, and duplexers/multiplexers
and other microwave passive components.
Focusing on cutting-edge fields such as 5G communication, satellite navigation,
radar electronic countermeasures, and aerospace, we provide customers with
high-performance microwave passive device integrated solutions.
We fulfill our corporate mission of achieving customer success with high-
quality products, attentive service and outstanding social responsibility, and
are committed to becoming a global benchmark in RF microwave components.

Minimum Order: 1 pieces
