500-2200W AC BLDC Motor Brushless EC 380V/220V High Power Variable Speed Fo

EC 380V/220V High power variable speed 500W-2200W BLDC motor for farm duty fan



Introduction

This page shows a high power EC/BLDC fan motor used in fan blower or air
conditioner units and similar applications, which need to drive fan blowers.

Till now, Hengsheng has a various of specifications of AC BLDC motors, and
different induction motor, geared motor, PM motor with gearbox. Because of its
long working life, stable performance and low failure rate, our products are
well received by customers. We have got the certification of CCC, RoHS and
ISO9001:2008.





Features of BLDC motor

1. Rated Voltage:200-240V 50Hz/60Hz

2. Output power range: 750W-2.2KW

3. Speed 300-1000 adjustable

4. The driver adopts the structure of aluminum shell completely closed, which
has high protection level and is safe and reliable.

5. The driver adopts independent installation structure, which is convenient
for disassembly and maintenance after sale.

6. The driver is integrated with three-speed, VSP10V,AC24V,PWM/PWF, RS485
control mode, and the function of speed feedback is optional.

7.Using infrared remote control, adjustable constant speed,constant torque, fan
coil unit load, cassette fan coil unit load.clockwise or counterclockwise
rotation

8.Using the same structure and installation method as the single-phase electric
power, it is more convenient to replace and popularize

9.Rated speed 1070 RPM, rated output power 750W, Max Torque 6.5 Nm.



Specification

140&160mm motor specification
PN A B C D E F G H K
Specification Rotation
12411001 6 φ25.4 M12*P1.75 35 35 49 84.7
102 325 160-220V-1.2KW-450rpm CCW
12511001 6 φ25.4 M12*P1.75 35 35 49 84.7
102 325 160-380V-1.2KW-600rpm CCW
16911006 6 φ24 M12*P1.75 35 35 49 84.7
102 325 160-380V-1.5KW-940rpm CCW
13411003 8 φ24 M12*P1.75 35 35 49 84.7
102 325 160-220V-1.5KW-940rpm CCW
16311001 6 φ25.4 M12*P1.75 35 35 49 84.7
102 325 160-380V-1.8KW-950rpm CCW
14711001 6 φ25.4 M12*P1.75 35 35 49 84.7
102 325 160-380V-2KW-1400rpm CCW
16411001 8 φ24 M16*P1.5 26 40 70 93
110 333 160-380V-2.2KW-950rpm CCW
12411003 8 φ24 M20*P1.5 30 45 78 95
112 335 160-220V-1.1KW-600rpm CW
12411005 8 φ24 M20*P1.6 30 45 78 95
112 335 160-110V-1.1KW-600rpm CW
12811003 6 φ25.4 M12*P1.75 35 35 49 51
72 289 140-220V-0.375KW-730rpn CCW
13011001 6 φ25.4 M12*P1.75 35 35 49 51
72 289 140-380V-0.375KW-500rpn CCW
12811001 6 φ25.4 M12*P1.75 35 35 49 51
72 289 140-220V-0.55KW-560rpm CCW
12911001 6 φ25.4 M12*P1.75 35 35 49 51
72 289 140-380V-0.55KW-890rpm CCW
12911003 8 φ24 M12*P1.75 35 35 49 51
72 289 140-380V-0.55KW-940pm CCW
12811006 8 φ24 M12*P1.75 35 35 49 51
72 289 140-220V-0.75KW-940rpm CCW
16911003 14 φ15 M10*P1.5 21 30 53 71
88 304 140-380V-1.1KW-940pm CCW
16311001 14 φ15 M10*P1.5 21 30 53 71
88 304 140-380V-0.75KW-940pm CW


500-2200W AC BLDC Motor Brushless EC 380V/220V High Power Variable Speed For
Farm Duty Fan 0

More information of Brushless DC Motor

A brushless direct current motor (BLDC: Brushless Direct Current Motor), also
known as an electronic commutation motor (ECM or EC motor) or synchronous DC
motor, is a synchronous motor that uses direct current (DC) power supply. The
brushless DC motor is essentially a permanent magnet synchronous motor that
adopts DC power input and becomes a three-phase AC power supply with an
inverter. There are various types of motors, and brushless DC motors are the
most ideal speed control motors today. It integrates the advantages of DC motor
and AC motor, not only has the good adjustment performance of DC motor, but
also has the advantages of simple structure of AC motor, no commutation spark,
reliable operation and easy maintenance. Therefore, it is well received by the
market and is widely used in automobiles, home appliances, industrial equipment
and other fields.
