50Hz Tissue Paper Production Line

PRODUCT DESCRIPTION
Hand Towel N AND Z Folded Folding Machine with glue lamination



HT210/215/225 N Folded Hand Towel Folding Machine



Features:

High speed:800-1000 sheet/min
Multifunction:hand towel and kitchen towel can be made
Control system:SIEMENS PLC
Parameters:

MODEL 3T 4T 5T 6T
Max. Width of jumbo roll 630mm 840mm 1050mm 1260mm
Slitting knife 3sets in back and front 4sets in back and front 5sets in
back and front 6sets in back and front
Vacuum pump 11Kw 11Kw 15kw 18.5kw
Main driving motor powe 4kw 4kw 5.5kw 5.5kw
Machine size 6×1.8×1.9m 6×2×1.9m 6×2.3×1.9m 6×2.5×1.9m
Machine weight 3500kg 4500kg 5500kg 6500kg
Machine speed 500-1000 sheet/min/lane
Max.diameter of jumbo roll Ф1200mm(other sizes can be ordered)
Inner diameter of jumbo roll Ф76.2mm(other sizes can be ordered)
Bankstand 2-6 jumbo rolls (should be ordered)
Embossing unit Steel to rubber,steel to paper,steel to steel(should be
ordered)
Lamination unit Should be option
Edge embossing unit Air bag type,bearing pattern(should be ordered)
Air pressure 0.8Mpa(user supplied)
