6meter Width Black 600gsm Woven Geotextile Fabric

PP High strength 600gsm Woven Geotextile Fabric



Description:



a monofilament polypropylene woven geotextile, widely used to improve soft soil
foundation ,

separate gravel course , discharge water and particularly has incomparable
advantages in

filtration. And Compared in the feature of filtration to the tradition woven
geotextile, it gains

widespread acceptance and use in wastewater screening .



Filtration : By woven into a regular network and calendared , the filaments
retain dimensional

stability relative to each other. These characteristics make it ideal for
preventing the passage of

fine soil granules and allowing passage of fluid.



Reinforcement : Safely limit the excursion of civil work over long time of use
and transfer or allocate

the stress on soil over a larger area



Separation : Separate the civil work materials into stable interfaces and
ensure them to function both

individually and as a whole.



Cushion buffer : Placed on a slope , it can prevent soil granules from being
flushed away



Corrosion resistance : The geotextile is resistant to ultraviolet degradation
and also to biological and

chemical environments normally found in soils.



Woven Geotextiles



High quality filtration fabrics that offer high tensile strength at low
elongation that come in variety of percentage open area options.

Woven Fabrics

These unique fabrics are made by extruding and slitting a polypropylene film,
then incorporating an ISO-9002 certified manufacturing process that weaves
individual flat yarns into geotextiles featuring high tensile strengths at low
elongation (high tensile modulus). These characteristics allow the geotextiles
to distribute loads, reduce rutting and extend the life of roads or provide
substantial sediment barriers.This process produces a premium filter that is
extremely resistant to soil and biological clogging. A full range of high
quality filtration fabrics has been created to offer designers several choices
for percent open area (POA), the single most important property in the
selection of a woven geotextile filter.

Applications include:

· Unpaved Roadways

· Paved Roadways

· Sediment Control

· Hard Armor Underlayment

· Subsurface Drainage

· Landfill Leachate Collection

· High tensile strength at low elongation

· Resistant to soil and biological clogging

· Available in a full range of high quality filtration fabrics for several
choices of percentage open area (POA)
