90° Buttweld Elbow

There are 45° short radius elbows and 45° long radius elbows.

Long radius elbows(LR elbow) provide smaller flow resistance and pressure loss,
and are suitable for general piping systems;

Short radius elbows (SR elbow) are suitable for limited space or situations
that require faster changes in flow direction.

The Buttweld 90 Degree Elbow offers superior flow dynamics in piping systems,
ensuring efficient fluid transport with minimal pressure loss.

Ideal for industries that require robust, leakproof connections, such as oil,
gas, and wastewater management.

Buttweld is used to connect the ends of pipes and fittings by a butt welding
process. Also known as welded pipe fittings. It has ended in beveled or plain,
dimensions normally from 3/4” to 24”. Manufactured according to ASME B16.9.
In various materials like carbon steel , alloy steel, and stainless steel.

The butt weld elbow is designed to change the direction of the fluid in the
piping system. It has a long radius (LR) and a short radius (SR) elbow types
and has different degrees of coverage to 45 degrees, 90 degrees, and 180
degrees. Buttweld elbow is a steel elbow formed by hot pressing or forging. Its
connection form is to weld the elbow and steel pipe directly. Butt-welded
elbows are mainly used for elbows with higher pressure and temperature than
other connection types (socket welded elbow or threaded pipe elbow).
Specifications
The Buttweld 90 degree Elbow is available in various sizes, making it suitable
for a broad range of applications. It’s specifically designed to handle high
pressures and temperatures, making it a versatile choice for demanding
industrial applications.

Choose the Buttweld Elbow 90 Degree for a dependable, efficient, and durable
solution in your piping systems. Its robust construction and precise design
ensure optimal performance in any setting.

Minimum Order: 100 sets
