99.99% Purity Copper Sheet Metal Plate AISI ASTM GB EN DIN JIS Standard

PRODUCT DESCRIPTION
99.99% Purity Factory Supply Copper Plate

Introduction

Copper Plate, made of pure copper or copper alloy in various shapes including
rods,wires, plates, strips,tubes, foils,ect.,collectively referred to as copper.
Copper materials include copper plates, copper rods,copper tubes,copper
strips,copper wires,copper bars,copper materials.
1. The surface of hot rolled plate should be clean; Delamination, cracks, peeling,
inclusion and green rust are not allowed, but repair is allowed, and the thickness
of the plate should not exceed the allowable deviation after repair.
The surface of hot rolled plate is allowed to have slight and local scratches,
spots, pits, pressed objects, wrinkles, roller
marks and other deviations that do not make the thickness of the plate exceed the
allowable deviation.

2. The surface of cold rolled plate should be smooth and clean; Delamination,
cracking, peeling, inclusion and green rust are not allowed.
The surface of the cold-rolled sheet is allowed to have slight and local scratches,
spots, pits, pressed objects, wrinkles, roller marks, oil marks and other
deviations that do not make the thickness of the sheet exceed the allowable
deviation.

Product Name Copper Plate/Sheet
Material Copper
Standard ASTM, AISI, JIS, DIN, GB, EN
Grade
TP1,TP2,C10930,C11000,C11300,C11400,C11500,C11600, , C12000,C12200,C12300
2C12500,C14200,C14420,C145 , 00,C14510,C14520,C14530,C17200,C19200,C21000,
C , 23000,C26000,C27000,C27400,C28000,C33000,C33200,C3 , 7000,C44300,C44400

,C44500,C60800C63020,C65 , 500,C68700,C70400,C70600,C70620,C71000,C71500,
,
C71520,C71640,C72200,TU1,TU etc

Shape Flat plate
Size Thickness 0.3mm~100mm;Width 50mm~2500mm; Length 1000mm~12000mm
Surface Mill finish, polished, anodizing, brushing,sand blasting, powder
coating,etc
Payment terms T/T,L/C,western union, Paypal
Price terms CFR,FOB,CIF,Ex-work,CNF
Application 1)Further making utensil.
2)Solar reflective film
3)The appearance of the building
4)Interior decorating:ceilings,walls,etc.
5)Furniture cabinets
6)Elevator decoraction
7)Signs,nameplate,bags making.
8)Decorated inside and outside the car
9)Household appliances:refrigerators,microwave ovens,audio equipment,etc.
10)The consumer electronics:mobile phones,digital cameras,MP3,U disk,etc.
Package Standard export seaworthy package or as required.
Contact If you have any question,please feel free to contact me.

Material China GB/T Japan JIS German DIN American ASTM UK
EN
TU0 C1011 -- C10100 C110
TU1 C1020 OF-CU C10200 C103
TU2 C1020 OF-CU C10200 C103
T1 C1020 OF-CU C10200 C103
T2 C1100 SE-CU C11000 C101
TP1 C1201 SW-CU C12000 --
TP2 C1220 SF-CU C12000 --

Composition(%)
TU1 Cu P O Other
TU2 99.97 0.002 less than 0.002 balance
T1 99.95 0.002 less than 0.003 balance
T2 99.9 - - balance
TP1 99.9 0.004-0.012 - balance
TP2 99.9 0.015-0.040 - balance
C10200 99.95 0.001-0.005 - balance
C11000 99.9 - - balance
C12000 99.9 0.004-0.012 - balance
C12200 99.9 0.015-0.040 - balance
