Advanced Quenching and Tempering Line with Induction Heating

This Long Bar Hardening and Tempering Heat Treatment is designed for steel bars
with a diameter of M8-M30. It uses a Dual-Channel Induction Power Supply System
(two independent power supplies for Hardening and Tempering) to achieve high-
intensity heat treatment process to ensure that the material strength grade
reaches the 12.9 standard. This line mainly consists of items such as IGBT
Induction Heaters and Induction Coils, Cooling System, Mechanical System,
Automation and Temperature Measurement.
Specification
Bar Diameter M8-M30
Bar length 3000mm to 6000mm
Hardening Temperature 850℃ to 900℃
Tempering Temperature 250℃ to 600℃
Maximum Production Rate  500kg/hour
Straightness 0.004mm/m
Bar material Carbon steels, special alloyed steel

Minimum Order: 1 tons
