All-in-one Integrated Home Energy Storage System

Solar Storage Wall ESS lithium battery is an integrated backup power system, a
multi-function inverter/charger / solar system. It plug and play, compact
design to help you save space. The energy storage system integrates the
inverter, battery and charger to provide users with convenient and
uninterrupted energy support.

The system is compatible with mains power, generator input, and diversified use
scenarios, and MPPT photovoltaic controller is added to support photovoltaic
power generation. The product has built-in intelligent BMS, with overload /
over temperature / short circuit/overcurrent protection function.

Detail of All-in-one Integrated home solar pv system
The 51.2V 100AH LFP Battery is compact, well-designed, LCD, and
cable/accessories ready for installation. ≥4000 cycles deep cycle & 5 years
warranty, designed for up to 20-year life.

2000W pure sine wave inverter, to meet the daily household load and small
equipment electricity, such as fans, microwave oven, refrigerator, air
conditioning, etc. Support the mains power and photovoltaic charging, to ensure
the safety of your electricity use at any time.
Specification of All-in-one Integrated integrated energy storage system
Battery Specs
Model 51.2V100Ah
Nominal energy 5.12KWh
Operating Voltage Range 43V - 58.8V
Output parameters
Continuous output power 2000W
Peak power 3000W
AC output AC220V 50HZ
USB 5V/2A
Type-c 5V 2A
DC output 12VDC /20A*2
Input parameters
PV input 12-90V 600W
Charger 48V10A
Charging Voltage Range
Rated charge/discharge current 50 A
Cell Configuration 16S
Operating temperature charge :0℃~+55℃
discharge:-20℃~+55℃
Storage temperature 0℃~+35℃ (max 6 months)
BMS Specs
Max Continuous Discharge 100Ah
Max Continuous Power 2500W
Max Peak Discharge 100Ah
Max Charge Current 100Ah
Communication interface CAN,RS485,RS232
Dimensions (W*H*D, mm) 770*450*220mm
Weight ≈55KG
Operating conditions
Installation location Wall mounted
Humidity 5%-95%
Altitude ≤ 4000 m
Cooling Natural cooling

Certificates
Safety IEC62619/EMC
Transport UN38.3

Outstanding Features of all in one home energy storage system
1. Intelligent fully automatic dynamic charge and discharge management
platform.

2. Multi-function digital tube display, real-time power, battery voltage,
charging status, discharge status, and inverter output mode.

3. SPWM pulse width modulation pure sine wave high precision low ripple
regulated output.

4. Pure sine wave AC 220V isolated output, no pressure with any load.

5. Built-in large-capacity, long-life, efficient and safe lithium iron
phosphate battery.

6. Intelligent BMS,battery management system can manage and monitor cells
status ,like voltage ,current ,temperature and protection for overdue ,which
can help to extend lifetime effectively .

7. It has short circuit, overload, over-temperature and other protection
functions, which is safe and reliable.

System Logic of All In One Home integrated energy storage System
All in one residential energy storage solution integrated inverter and lithium
iron phosphate battery, reduce the inverter and battery matching communication
problems, debugging time and procurement costs. This battery system can realize
intelligent voltage switching and meet the operation needs of various
equipment.

For more information about off grid solar pv system, please feel free to
contact us!

Minimum Order: 600 pieces
