ANSI / ASME B18.2.2 Flange Nuts

ANSI / ASME B18 2.2 PDF Flange Nuts
The ANSI/ASME B18.2.2 automotive flange nuts / flange bolts and nuts and
the general hex nut are basically the same in size and thread specification.
Whereas, compared with the ASME B18 2.2 hexagon nut, the gasket and the flange
nut are integrated, and there are anti-skid tooth patterns on the bottom, which
increases the nut and the workpiece. Compared with the combination of ordinary
nut and washer, the ANSI/ASME B18.2.2 flanged nut is firmer and has greater
tensile force. The flange nut surface itself has the anti-slip and stop
functions of the flat washer and the spring washer, so there is no need to add
the flat washer and the spring washer during assembly, which will be
counterproductive. It is widely used as automotive flange structural nuts.

ANSI / ASME B18.2.2 Automotive Flange Nuts Specifications
ASME B 18.2.2 Automotive Flange Nuts
ASME B 18.2.2 - 2015 12mm/13mm/14mm Flange Nuts

Datian ANSI / ASME B18.2.2 Flange Nuts Dimensions

Legend Making
P=pitch Carbon Steel:6,8,10,12
K=height of the nut Thread:6H
D=the nominal diameter of the thread Surface:BLK,ZP,HDG,etc
E=The length of the diagonal
S=The length of the flat

Now the fastener price is affordable, if you have needs to buy any related
products for sale, if you have needs, please contact us.

Minimum Order: 1 metric tons
