ATP200 Carousel Tissue Processor

Experience seamless tissue processing with our Carousel Tissue Processor. This
advanced laboratory equipment automates sample fixation and dehydration,
optimizing workflow efficiency while maintaining sample integrity for precise
histopathological analysis.

Description of ATP200 Carousel Tissue Processor
1. Robust equipment, easy to handle, mounted in tubular frame plate in high
resistance plastic resin finishing.

2. External finishing in white, resistant to the lab environment and xylol
products.

3. Micro-processed central digital touch screen LCD panel, which controls all
functions of equipment such as date, time and year and equipment adjustment
parameters configuration.

4. Daily schedule for 24 hours and sloe time setting for weekends or extended
holidays.

5. Changeable programming with selectable time interval according to the need
of the operator. Ability to pause processing in any bath or position.

6. Adjustable bath speed and time control allowing total flow, fully preventing
contamination of one bath to other.

7. High duration battery own up to 10 years allowing data protection even in
lack of power situations.

8. +/- 20 min continuous operation in lack of power situation. Energy provided
by no break variable according to no break capacity.

9. Protection sensor that controls paraffin mugs individually with visual and
sonorous alarm protection for sub and super heating.

10. System protection not allowing the penetration of the last xylol paraffin
bath, in case of not agreeable selected temperature parameter.

11. Automatic stop at end of system cycle, 9 storage protocols programs pre-
selected by operator.

12. System oscillation inox basket with capacity up to 85 cassettes which
improves the processed material quality.

Specification of ATP200 tissue processing machine
Paraffin Bath Temperature Control in panel, with adjustable sensitivity to
80±1 C.
Capacity up to 255 plastic cassettes using 3 baskets
Capacity to 10 Reagent baths and 2 paraffin baths, total 12 baths of 2L each
Sealant bath lid that fully prevent environment contamination
Height 800mm
Width 530mm
Weight 70kg
Power 500 W
Voltage 220V at 50/60 HZ

For more information about tissue processor machine price and histopathology
laboratory equipment, please feel free to contact us!
