Auto Cold Drawing Machine - HS300

Description:
1. Motor: 50HP/75HP
2. Applicable material: brass, aluminium, steel and alloy rod
3. Applicable size: Ø15~50mm/40mm
4. Working range: 8~25%


Applications and features:
1. Seesaw-type drawbench with the chain-driven carriage to pull out the
rolled or extruded tubes for better precision.
2. Equipped with push pointer for pointing process, substituting lathing or
shrinking the end of bar process before the cold drawing.
3. Cold drawn materials improve the hardness, yield and tensile strength of
the material.
4. Option to combine length cutting or straightening processes after cold
drawing for better production efficiency.
5. Pulling force, speed, and drawing length could be custom-made according
to the practical process deriving from the material composition.
6. Relevant working processes: Extrusion, sand-blasting, pickling,
coating, heat treatment, cutting, straightening
