Automatic Fire Extinguisher Cabinet Machinery

New design galvanized steel various fire hydrant box production & Outdoor fire
hydrant cabinet accessories,fire extinguisher cabinet roll forming machinery.

Equipment for producing galvanized steel /mild steel fire hydrant cabinets with
different dimension available.
Electrical control system
The entire line imported PLC control, LCD touch screen, man-machine interface.
People interact with the PLC. Operator setting the program to run automatically
(programmable control) and control process monitoring, production line operator
control and modify the control parameters, and real-time monitoring the
equipment status & parameters and fault indication. Workpiece length digital
setting, adjustable length can be adjustable as well. Real-time monitoring of
equipment operating status and fault indication.
Operation manual / automatic two styles. With manual and automatic switching
function: In the manual mode, can be stand-alone operation, easy maintenance;
In automatic mode, carry out full production run, in order to start; across the
board with emergency stop buttons, easy to handle emergencies, to ensure that
equipment and operating personnel Safety.


Machinery main components of the brand:
PLC control system: Siemens
Inverter: Taiwan Shilin
Encoder: Omron
Touch screen: Siemens
Some components are Schneider brand devices.


Devices completed fire extinguisher cabinet production line

No. Machine name QTY REMARK
1 Uncoiler, straightener 1
2 Servo Feeder 1
3 Hydraulic machine 2 With mould
4 Guide device 1
5 Forming machine 1
6 Hydraulic station 2
7 Follow Shear 1 Including knife
8 Collect rack 1
9 Control system 2
10 Box bending device 1 With mould


Steel metal box machine accessories brand

No. Name manufacturer
1 Motor & Reducer Domestic brands
2 The main key bearing Domestic brands
3 Inverter Shilin
4 PLC Systems Siemens
5 Low-voltage electrical Schneider
6 Encoder Omron
7 touch screen Siemens
8 Hydraulic system Domestic brands

Minimum Order: 1 sets
