Black flame-retardant plastic Polycarbonate films

Polycarbonate Films Spec.
Property Test Method Units Value
Physical
Specific Gravity ASTM D792 G/cm3 1.2
Water Absorption Equilibrium,24Hrs ASTM D570 % 0.35

Tensile Strength ASTM D882 Psi 8,800
ISO R1184-1987 Mpa 60
Elongation Ultimate ASTM D882 % >90
Impact Strength @ 10mils JIS-k6745 In-ibs 120
Tear Strength Propagation ASTM D1922 G/mil >30
Temperature Resistance
Vicat Softening Temperature ASTM D1525 ℃ 110
Heat Shrinkage Rate ASTM D1204 % <1.0
Electrical
Dielectric Strength (@ 10 mils) ASTM D149 V/mil 1700
Volume Resistivity @25℃,50%RH ASTM D257 Ohm.m 1016
Surface Resistivity @25℃,50%RH ASTM D257 Ohm 1015
Flammability
UL 防火等级 UL Flammability UL BULLETIN94 　 　
@ ≥ 10 mils 　 UL94 V0
@ ＜ 10 mils 　 UL94 VTM-0
Property Unit Ultimate Value
Gaute Variation % ＞0.5 ±0.006mm
≦0.5 ±0.004mm

Minimum Order: 500 kilograms
