closed loop water cooling system

What is closed-loop cooling?
A closed-loop water cooling system maintains optimal temperatures inside a
sealed enclosure while keeping warm ambient air, moisture, dust and other
airborne contaminants out. By circulating cool, clean air within the
electrical enclosure (and through the heat-generating components), closed-
loop cooling systems help protect sensitive electronic components and extend
their life. In a typical closed-loop air conditioner, heat is transferred
from the enclosure components by circulating air around and through them.
The air is then cooled, dehumidified and returned to the enclosure without
allowing air from outside the enclosure to enter. Heat is removed from the
air inside the air conditioning unit and discharged through the vapor
compression refrigeration cycle.
Specification：
Model：TY-35/110T
Power Input：380v, 3ph, 50hz
Cooling Capacity：175，000/550,000 kcal/h
Fan Power：4kw x2
Fan Air Flow：80000 m3/h x 2
Spray Pump：3kw, 150m3/h, 5m
Main Pump：15kw, 100m³/h, 36m (for Inductors or transformer)7.5kw, 50m³/h,
32m (for induction power supply)
Inlet/Outlet：DN125/DN80
Working Pressure：0.1 to 0.3 MPa
closed loop water cooling system Features:

Minimum Order: 1 tons
