CNC Cylindrical Grinding Machine MA2060/MP2060

Provide a complete solution for cylindrical and end face grinding of shaft and
disc parts, it can carry with truss or joint robot and automatical line.
Cylindrical grinding machine is a kind of grinding machine used to reshape the
exterior of objects. Cylindrical grinders can process various shapes, but the
object must have a central axis of rotation. This includes, but is not limited
to, shapes such as cylinders, ellipses, cams, or crankshafts. The hydrostatic
guide rail and hydrostatic spindle form the basis of the high-precision
cylindrical grinding machine series. They can be equipped with automation and
are especially suitable for processing workshops and manufacturing.
Technical Parameters
ITEM MA2060 MP2060
Max Tow Centre Distance, mm 600 600
Max Table Rotate Diameter, mm Ø400 Ø400
Max Loading, kg 80 80
Max Workpiece Diameter, mm Ø190 Ø190

Click to Enlarge
