Container Tracking

Container tracking products is containe's terminal positioning equipment,
conveniently installed In ihe container ventiLAlation hole; keep original
container structure; acquiring the location of container and status data of
that with Internet of Things Technology; optimize control container management
business.'

Container gps and temperature tracking can reduce costs (operation and
maintenance) for container owners and cargo owners, improve cargo supervision
capabilities, optimize deployment plans, reduce transportation risks and
improve management efficiency for users.

Product Description

Supporting For Third-party Data Docking
Supporting for third-party data docking, record historical positioning data of
container and movement trajectory of that according to the reported data

cimc-itech
Wide range of applications and that of scenarios
Can be used for multimodal transport, shipping, import and export and port
terminals, etc.

The Advantage of Product

Bluetooth Smart
It uses Bluetooth 5.0 and 3-axis acceleration, and judges the behavior status
of the terminal in real time through the algorithm, and further distinguishes
the transportation status (Road Transportation, Sea Transportation, Standstill
Status) of the terminal.

Super Long Life
The ultra-low standby current of 6uA can extend the operating life (over 5
years) of the terminal.

Battery Stability
By using a customized battery pack, the terminal equipment can operate stably
at -40°C-85°C.

Supporting For Iteration
Support remote batch upgrade to ensure product upgrade.

Wide Of Communication Adaptation
The communication uses 2G / 3G / 4G global communication module, which can
obtain terminal data in more than 200 countries around the world.

Precise Positioning
The positioning adopts dual system + AGNSS auxiliary positioning, which
shortens the positioning time and improves the positioning accuracy.

System Structure

Hardware Terminal
It is a remote communication device and sensor for dry container tracking.

Communication Mode
Data transmission in global through technologies such as cellular networks, IoT
technology or LEO satellite communication, etc.

Data Service
Using IoT technology to obtain container location and status data, Provide
stable and reliable data management services for customers

User Guide

01
Assembly Instructions

02
Scan QR code to tracking contaniners

03
The showing of system platform

Equipment Detailed Parameters

Size 205mm*67mm*34mm Temperature Detection Ambient Temperature
Detection
Waterproof Grade IP67 Battery Detection Battery
Information Detection
Total Capacity 18000mAh Operational Life 5 ~ 10 years
Standby Current 6uA Bluetooth Version Bluetooth 5.0
Shell Material ABS Engineering Plastic + High-strength PC (anti-aging)
Bluetooth Device Function Device initialization settings, Support
reporting interval, Device reset, etc.
Battery Module ER14505*7+SPC1550A*1 Range of Bluetooth
Communication 25 Meters
Working Current ＜80mA Motion Detection The device can switch
the collection/report frequency according to motion/stillness
Operating Temperature -40℃—+85℃ Location Status Calculate the
state of the terminal (Road Transportation, Sea Transportation, Standstill
Status) through algorithms, etc.
The Accuracy of GPS ≤2.5m GPS Frequency GPS L1 1575.42MHz/BDS
1561.098MHz
Positioning Mode GPS/BDS/LBS Data Storage Under the
condition of without network, 500 pieces of positioning information can be
stored
Sensor 3-Axis Acceleration Sensor

As the best container management platform, we can offer reliable container
inventory management software for clients, if you have needs, please contact
us.

We also have high quality temperature sensor gps tracker for sale, anything you
need, please leave us a message.

Minimum Order: 1 pieces

Click to Enlarge
