CPCI Subrack

CPCI Subrack Module CompactPCI Wholesale Cpci Subrack

Product Description

CPCI (Compact Peripheral Component Interconnect) Subrack——3U, 4U Horizontal
Subrack
Structure Characteristic:
19" standard subrack, all subrack considered the EMC(electro magnetic
compatibility); the depth of side plate is 405mm;
3U configured 5 groove(4TE)s;4U configured 7 grooves(4TE); for horizontal
installation of 6U×160 plug-in card;
Back panel can install fan and power source;
Radiating wind enter from the intake in front panel, transverse pass the plug-
in card and discharge through the fan;
The whole subrack meet the requirement of IEC60297.
1. EMC subrack basic configuration
2. Cover plate
3. Back panel
4. Fan
5. Air baffle
6. Horizontal installation panel suite
7. 5TEpanel
8. Plastic card guide rail
9. Horizontal installation suite

CPCI (Compact Peripheral Component Interconnect ) Subrack——4U, 7U Subrack
Structure Characteristic
19" standard subrack, all subrack considered the EMC(electro magnetic
compatibility); the depth of side plate is 405mm.
4U is used for horizontal installation of 3U×160 plug-in card.
7U is used for horizontal installation of 6U×160 plug-in card.
Back panel can install power source.
Radiating wind enter from bottom plate, pass the plug-in card and discharged
through the cover cover.
The whole subrack meet the requirement of IEC60297.
1. base system of the components subrack
2. bottom plate/cover plate, the way of ventilation
3. finger protection
4. support frame of the fan
5. plug-in guideway
6. 1U face plate/ 84HP
7. back panel
8. DC fan(direct fan)
9. composite member with all-in-all filter and ICE socket
10. power source
11. Back plane bus
12. direct connect cable
13. alternating connect cable
14. direct fan module

CPCI(Compact Peripheral Component Interconnect ) Subrack——7U Subrack
Structure Characteristic
19" standard subrack, all subrack considered the EMC(electro magnetic
compatibility); the depth of side plate is 405mm;
7U is used for installation of 6U×160 plug-in card.;
Back panel can install fan and power source;
Radiating wind enter from bottom plate, pass the plug-in card and discharged
from back panel by fan;
The whole subrack meet the requirement of IEC60297.
1. base system of the components subrack
2. cover plate with 1/2U edgefold
3. bottom plate with 1/2 edgefold, ventilation in the front.
4. air deflector
5. air current partition
6. plug-in track
7. back panel
8. direct current fan
9. composite member with all-in-all filter and ICE socket
10.power source
11.back plane bus
12.direct fan module
13.direct connect cable
14.alternating connect cable
15.LED display control module

CPCI(Compact Peripheral Component Interconnect ) Subrack——9U Subrack
Structure Characteristic
19" standard subrack, all subrack considered the EMC(electro magnetic
compatibility); the depth of side plate is 405mm;
9U is used for installation of 6U×160 plug-in card;
Back panel can install power source;
Radiating wind enter from bottom plate, transverse pass the plug-in card and
discharged from back panel by axial fan;
The whole subrack meet the requirement of IEC60297.
1. base system of the components subrack
2. bottom plate/cover plate
3. EMC backwall
4. EMC panel
5. EMC connect profiles
6. plug-in guideway
7. plug-in guideway for input/output
8. panel 1/2 can overturn
9. panel 1/2, ventilation type, openable
10. EMC backwall, ventilation type
11. EMC backwall with a opening of power plug
12. filter pad, pushable
13. installation plate for RiCool
14. direct current fan
15. all-in-all filter and IEC socket
16. power source
17. back plane bus
18. alternating connect cable
19. direct connect cable
20. display module
21. power switch
22. monitoring module for RiCool
23. power source for RiCool
P23Sheet Metal Ahassis

IDU11Z Sheet Metal Chassis
Material: electro-galvanized steel of superior quality
Characteristic:
Compact structure design, can insert two small cards;
Outside surface use electrostatic spraying and printing;
Extensive used in electron industry.

Entrance Guard Chassis
Material: electro-galvanized steel of superior quality
Characteristic:
Outside surface use electrostatic spraying and printing;
Extensive used for electron industry.

UPS power supply, several kinds of ups electrical system are sold. We provide
UPS power supply program support. Jiancheng is also a charging pile supplier
about integrating technology, after-sales, installation and maintenance.

https://www.jch-electronics.co , m/product-cpci-subrack.html

CPCI Subrack
