Desand Cyclone and Germ Cyclone

HongVadar company provides you the Lysine, Tryptophan, Threonine, Valine,
Leucine, etc. fermentation products project. HongVader as agricultural
processing plants play the roles of corn, sweet corn processing plant, potato
processing plant, starch of corn and wheat processing plant, taking wheat,
rice, cassava processing, msg project, and production lines of ethanol glucose,
DMH, fructose, sorbitol.

Desand Cyclone
HVD-CY-DS series desand cyclone is mainly used in starch production to remove
sediment, metal particles, and other impurities in starch milk. The desanding
hydrocyclone for sale is also suitable for removing heavy phase impurities in
other fluids. There are two kinds of cyclone particle separator bodies:
stainless steel cyclone separator & ceramic and high-strength wear resistant
plastic. Advanced design, easy installation, and high efficiency of sand
removal.

Desand Cyclone Working Principle
Under the pressure of 0.5MPa, the starch milk enters along the tangent
direction of the desander and generates centrifugal force due to the rotary
movement. Due to the different specific gravity of the material, the heavy
phase impurities such as sand are thrown to the periphery and discharged along
the inner wall from the bottom. And the starch milk overflows through its upper
overflow pipe into the next process.

Desand Cyclone Technical Parameters
HVD-CY-DS series desand cyclone

Model Capacity, m3/h Feed pres., MPa Desand efficiency, % Remarks
HVD-CY-DS1 30-35 0.5 ≥97 2+1 cyclones
HVD-CY-DS2 60-70 4+2 cyclones
HVD-CY-DS3 90-100 6+2 cyclones
HVD-CY-DS4 120-130 8+2 cyclones
HVD-CY-DS5 150-160 10+2 cyclones

Degerm Cyclone
HVD-CY-GM series germ cyclone separator use is mainly about separating the germ
after the corn is coarsely broken. As one of the two types of single cyclone
separator, this equipment is static with simple structure, advanced design,
easy installation, and large production capacity range.

Germ Cyclone Working Principle

The crushed material enters from the tangent direction through the feeding
inlet under a certain pressure. Due to the different specific gravity of the
germ and the corn slurry, under the action of centrifugal force, the free germ
discharge through the overflow outlet, and the corn slurry is discharged from
the lower part.

Germ Cyclone Technical Parameters
HVD-CY-GM series germ liquid cyclone


HongVadar relies on professional design, strict production management, the fine
processing procedure, provides high efficiency and energy-saving equipment
system for the customer. The manufacturing factory has passed the international
ISO9001 quality system certification, and with the design and manufacturing
capacity of pressure vessels. Customers can choose international ISO, EU CE,
and other standards for equipment design and production according to their
needs.

Desand Cyclone and Germ Cyclone Parameters
Desand Cyclone Technical Parameters
HVD-CY-DS series desand cyclone


Germ Cyclone Technical Parameters
HVD-CY-GM series germ cyclone


If you want to know hydrocyclone price and cyclone separator price, please
contact us.

Minimum Order: 1 sets
