Desktop environmental simulation temperature and humidity test chamber

The environmental test chamber is suitable for the adaptability tests of
electrical and electronic products, components and other materials under
different humidity conditions. It can simulate different environmental
conditions such as temperature, humidity, vibration and low air pressure to
test the performance and reliability of the products.
Working principle: The environmental test chamber system adopts a method of
balancing heating and cooling, as well as humidification and dehumidification
for temperature and humidity control. The controller compares the temperature
and humidity values detected by the temperature and humidity sensor with the
set values of the controller. After a series of operations, it adjusts the on-
off time of the heating and humidifying solid-state relay, thereby achieving
the purpose of regulating the heating and humidifying power.If you need more
models about our test equipment, please reference our https://www.chamber-
testing.com/
Technical Specifications
Benchtop environmental test chambers

Capacity: 22.5 to 64L

Temperature Range：-65℃ to +150℃

Temperature Fluctuation：≤ ±0.5℃

Temperature Deviation：≤ ± 2.0℃

Humidity Range： 20% to 98%R.H

Humidity Deviation：± 3.0% RH(>75%RH)

Noise test：≤ 68dB

Minimum Order: 1 packs
