Ductile Iron Pipes

Product Description Of Ductile Iron Pipes&Fitting
1:Products Size:DN80-DN2600
2:Standard of BEISAI :
National Standard: GB/T13295-2003
International Standard: ISO2531-2009
European Standard: EN545/EN598
UK Standard: BS EN545-2002
American Standard: AWWAC 151
South Korean Standard: KSD 4311
Australian Standard: AS 2280
3:EN545/ISO2531/GB/T13295 Ductile Cast Iron Pipe unit weight ,T-type  K8 K9
K10 C Class ,Active Length = 5.7/ 6M.
4:Mechanical property of Ductile iron pipes & fittings Exporter
Nominal   Diameter Hydraulic test Tensile strength Elogation
Yield strength Bending strength Brinell hardness
DN(MM) Mpa Mpa % Mpa Mpa HB
DN80-DN300 5 ≥420 ≥10 ≥300 ≥590 ≤230
DN350-DN600 4 ≥420 ≥10 ≥300 ≥590 ≤230
DN700-DN1000 3.2 ≥420 ≥10 ≥300 ≥590 ≤230
