Full Automatic Osb Board Making Machine

100-700Cbm/Day MDF/HDF Multi-Opening Press Line with Advanced Technology

Fully Automatic 100~700 Cbm Per Day MDF/HDF Multi-Opening Press Production
Line



Description

Whether your multi-opening press is heated by electricity, steam, or fluid,
the consistency of this heating is key. a multi-opening press platen
manufacturer that makes custom press platens heat easily and uniformly to
ensure products are produced with matching dimensions. Given the nature of a
multi-opening press, if all openings are not receiving the same level of
heat, production can be spotty and lead to material waste, extending
production time, and frustration for your team. Thankfully, the right custom
platens will provide the heat your multiple opening presses require to
produce parts as intended.



The 180-700m³/day MDF/HDF production line uses raw material through chips
preparation, fiber manufacturing, glue dosing system, forming and hot
pressing, cooling &trimming and sanding section to make MDF/HDF board. The
final size can be 4 x 8, 6 x 8, 6 x 9, 4 x 12, 6 x 12, 6 x 18. The MDF/HDF
board has homogeneous structure, smooth surface, good machining
specification and manufacture performance. It is the ideal substitute of
nature wood.



Summary of process flow



Full Automatic Osb Board Making Machine 0



Chips Preparation Section
Fiber Preparation Section
Glue Dosing System
Drying Section
Forming and Hot Press section
Sanding and Cutting Line


Main technical data



Item Unit Specification
Capacity m³/d 100~700
Width of production line feet 4,6
Final board thickness mm 8~30
Final board width mm 915~1830
Final board length mm 1830~5490
Press Layers daylight Max. 32




Key equipment of production line

Drum chipper
Full Automatic Osb Board Making Machine 1

Refiner
Full Automatic Osb Board Making Machine 2

Forming line
Full Automatic Osb Board Making Machine 3

Hot press
Full Automatic Osb Board Making Machine 4

Sanding line
Full Automatic Osb Board Making Machine 5
