Fully Automatic Wheat Bag Grain Packing Machines AC380V 2.5KG CCPIT

Fully Automatic Grain Vacuum Packing Machine

QZB-900E Fully automatic PE,pillow shap vacuum and filling CO2 packing
machine





Air pressure:0.5～0.7MPa.

Air consumption:When working with filling CO2: 67L/min；When working with
vacuum 117L/min.

Power:AC380V±10%,50Hz,Three-phas , e five-wire system,Grounding form:TN-S

When working with filling CO2:5.6KW；When working with vacuum:10KW.

Working temperature:0～40℃.

Ambient humidity: no more than 90% RH at 40 ° C, and greater humidity is
allowed at low temperatures.

The dimensionof machineL×W×H(mm):7576×2294×2780



Model QZB-900E
Filling way One time one bag filling
The package of bag PEbag
Quantity(kg/bag) 2.5～10
The sealing way Filling and normal PE sealing one time,vacuum sealing two
times
