GB5725-2009 Class B Fine Mesh Vertical Safety Net Rope

GB5725-2009 Class B Fine Mesh Vertical Satety Net

Description:

GB5725-2009 Class B Fine Mesh Vertical Satety Net which mesh aperture is not
more than 12 mm, perpendicular to the horizontal installation, to prevent
personnel, the line of sight, natural wind, splash and small objects out of
control network without falling risks or combined with vertical safety nets to
achieve protection from falling.Class B Fine Mesh Vertical Safety net is
generally composed of network body,round button with hole,border ropes and tie
ropes. The net body is braided by the net rope and has a diamond or square
mesh.Round button with hole is made of metal or other hard material . The
material of safety net requires small proportion, high strength, good wear
resistance, large elongation and strong durability. Safety net with chemical
fiber as the main material.



Main Technical Specifications:

1.Standard: GB5725-2009

2.Material: PE,HDPE,PP,Ployester,Nylon

3.Size: Width(1.2-2m),Length as ordered(Min. 2m)

4.Type: Knit

5.Test: Breaking stress, breaking elongation,streching resistance at unwelded
joint,trapezoidal method tearing stress,round botton with hole stress, tie
ropes breaking stress,impact stress,flame retardent proporties

6.Classification Certificates: RINA, BV, CCS, KR, NK, ABS, DNV, LR, RS, IRS,
EC, TUV and Mill Certificate

7.Color: White, or as ordered

8.Application: Saffolding safety nets,cargo,gangway,debris,building protection,
All kinds of construction sites, especially high-rise buildings, can be
completely closed construction

9.Advantages: High strength, good resistance, strong durability,high mesh
density,stable,cheap,light,heat resistance,nice ventilation,



Main Technical Parameters:

GB5725-2009 Class B Fine Mesh Vertical Satety Net

Items Desciption Remark
Material PE,HDPE,PP,Ployester,Nylon
Width 1.2m-2.0m
Length as ordered(Min. 2m)
Minimum breaking strength x breaking elongation ≥50KN·mm
Tie ropes breaking stress ≥2000 N
Impact Resistance Impact height 1.2m
Impact result Edge rope not fractured,Net body fractured holes not more than
200x50 mm
