Hammer

TAIYE, as one of the most professional drilling equipment manufacturers,
provides types of hammers, such as the pneumatic hammer, the rock hammers, the
hydraulic hammer and the hole DTH rock hammer (down the hole hammer) for all
rock drilling applications, including but not limited to foundation and
geotechnical drilling, blasthole drilling in quarries and mines, water and
geothermal drilling.

dth hammer Description Bit Shank style Thread Piston Case
Effective length (mm) Weight (kg) Rec.hoie size (mm) Working
pressure bar Applicable rock type
Shank style Foot valve Api Pin D×L
mm×mm

DTH-3.5＂ DHD3.5 Without 2 3/8＂REG Φ80×729 853 22
90-105 6-25 High frequency/energy-efficient Soft to medium rock

DTH-4＂ DHD340A Without 2 3/8＂REG Φ99×758 912 39 108-130
6-25 High frequency/energy-efficient Soft to medium rock

DTH-5＂ DHD350R Without 2 3/8＂REG
3 1/2＂REG Φ126×830 976 68 134-152 6-25 High
frequency/energy-efficient Soft to medium rock

DTH-6＂ DHD360 Without 3 1/2＂REG Φ144×967 1163 120 155-200
6-25 High frequency/energy-efficient Soft to medium rock

DTH-8＂ DHD380 Without 4 1/2＂REG Φ180×1045 1312 188 200-305
6-25 High frequency/energy-efficient Soft to medium rock

Minimum Order: 1 sets
