HASTELLOY C-276/N10276 NICKEL ALLOY PIPE/TUBE

Hastelloy C-276/N10276 Nickel Alloy Tube has a relatively higher molybdenum
content than C22. And the Hastelloy C276 seamless pipe is made with seamless
craftsmanship.

HASTELLOY C276 PIPE SPECIFICATION

Steel Grade N06022,N10276 Type Seamless
Standard ASTM, AISI, GB, DIN, JIS Certification
ISO,SGS,BV,ISO/CE/SGS
Length 15000mm Max, Customized Thickness 0.508-50.8mm
Technique Cold Rolled, Cold Drawn Min./Avg. Avg.
Outer Diameter 6.35-406.4mm, Customized Finish Brush Polish Cold
Drawn, Pickled,Bright Annealed

HASTELLOY C276 SEAMLESS PIPE CHEMICAL COMPOSITION

Chemical Composition C Mn P S Si Cr Ni
Mo Fe
N10276 0.01 1.00 0.04 0.03 0.08 20-22.5 Balance 15-17 4-7

HASTELLOY C276 TUBE MECHANICAL BEHAVIOR

Mechanical Behavior TS YS Elongation
MPa MPa %
N10276 690 283 40

HASTELLOY C276 UNS N10276 TUBING PIPE HIGHLIGHTS

Hastelloy C276 is a Ni Cr Mo wrought alloy and is considered the most common
corrosion-resistant alloy. The alloy C276 is resistant to the formation of
grain boundary precipitates in HAZ, so it is suitable for most chemical process
applications in welding conditions. ASTM Hastelloy C276 also has excellent
resistance to pitting corrosion, stress corrosion cracking, and oxidizing
atmospheres up to 1900°F. Alloy C-276 has excellent resistance to a variety of
chemical environments.

As one of the hastelloy c276 pipe manufacturers, we provide astm b622 uns
n10276, astm b619 uns n10276, b622 uns n10276, uns n10276 pipe, hastelloy c276
astm, steel tubing connectors fittings, etc. For more information, please feel
free to contact us!
