HDA Heavy Slurry Pumps

Slurry pumps are recommended for pumping liquids containing small or large
suspended solids.They are designed for continuous pumping of highly abrasive
and corrosive slurry.
The excellent performance of slurry transportation depends by its special
designed structure:
1. Liner 2. Frame Plate 3. Frame Plate Liner Insert 4. Cover Plate 5. Cover
Plate Liner
6. Cover Plate Liner 7. Expeller ring 8. Shaft Sleeve 9. Expeller 10. Bearing
Seal
More information you can click here
ump Model HDA Series Pumps ImpellerDia.(mm)
AllowableMax.Power Clear Water Performance
Capacity Q Head
H(m) Speed
n(r/min) Max.Eff.
η% NPSH
(m)
m3/h l/s
1.5x1B-HDA 15 12.6-28.8 3.5-8 6-68 1200-3800 40
2-4 152
2x1.5B-HDA 15 32.4-72 9-20 6-58 1200-3200 45 3.5-8
184
3x2C-HDA 30 39.6-86.4 11-24 12-64 1300-2700 55
4-6 214
4x3C-HDA 30 86.4-198 24-55 9-52 1000-2200 71
4-6 245
4x3D-HDA 60
6x4D-HDA 60 162-360 45-100 12-56 800-1550 65 5-8
365
6x4E-HDA 120
8x6E-HDA 120 360-828 100-230 10-61 500-1140 72 2-9
510
8x6R-HDA 300
10x8ST-HDA 560 612-1368 170-380 11-61 400-850 71 4-10
686
12x10ST-HDA 560 936-1980 260-550 7-68 300-800 82 6
762
14x12ST-HDA 560 1260-2772 350-770 13-63 300-600 77 3-10
965
16x14TU-HDA 1200 1368-3060 380-850 11-63 250-550 79 4-10
1067
https://www.topslurrypump.com/product- , hda-heavy-slurry-pumps.html
Remark:
1. Capacity range recommended: 50%Q'≤Q≤110%Q' (Q' Appropriate to capacity at
highest efficiency point).
2. NPSH: appropriate to point Q recommended at highest speed
Hedun-Metal Lined Slurry pump Typical Applications
1. Coal washing plants
2. Mining
3. Oil and gas
4. Sand and gravel plants
5. Dredging for mineral sands
6. Ash handling facilities attached to power stations

Minimum Order: 1 sets
