Horizontal Loading Autoclave Steam Sterilizer Benchtop Lab 240 Liters

Benchtop Lab Autoclaves Front Loading Autoclave Horizontal Loading Steam
Sterilizer



Features

* Brand-new operation interface: The LCD touch screen can display real-time
information such as temperature, pressure, time, operating status, fault alarm,
and equipment operating curve, making the sterilization information more
intuitive and clear, and it is convenient for users to observe the operating
status of the equipment.
* Multiple safety protection devices: automatic over-temperature protection
device, multiple control and protection of evaporator, door safety interlock
protection, double over-pressure protection device, etc.

* Vacuum system: It adopts high-efficiency vacuum system, low working noise,
ultimate vacuum can reach more than -80KPa, fast pumping speed, good dryness of
items, and more thorough sterilization.
* Diversified procedures: There are fast procedures, encapsulation procedures,
rubber procedures, dressing procedures, liquid procedures, liquid
customization, solid customization, media sterilization, media dissolution and
other procedures, as well as B&D testing and vacuum testing procedures.
* High-efficiency air filter: 0.22pm sterilizing high-efficiency air filter,
the filtration efficiency is not less than 99.5%, to ensure that the vacuum-
breaking air is sterile air, and to avoid re-contamination of sterile
materials.



Description



The steam sterilizer with vertical sliding doors provides the best
prerequisites for professional

sterilization in the laboratory. The MD series is the most efficient and most
compact sterilizer

in its class. It complies with all relevant guidelines and standards.



Specifications



Model

MD-0.24V

Door number

double door(s)

Door type

Vertical sliding door

Chamber and jacket material

SS304 / SS304

Chamber volume

240 liters

Chamber Size

600*600*670mm

Overall Size

1300*1800*1010mm

Net Weight

700kg

Steam

20Kg/cycle

Water

23Kg/cycle

Power(KVA)

2KVA

Sterilization temperature rage

105°C to 134°C

Sterilization time rage

0---99 minutes

Vacuum times

0---9 times

Drying time

0---99 minutes



Application



Medpharmoffers total sterilization solutions in the pharmaceutical, life
science, biotechnology, laboratory and animal care markets.



All MD Series sterilizers include Pre-Vacuum, Liquid, Bio-Bag, Hard Goods,
Bowie-Dick test and Vacuum Leak Test cycle as standard.



Features and Benefits



1. Lowest Cost of Ownership



Design characteristics from years of service experience are engineered into the
MD Series

sterilizers.



Industrial grade components, precision machining and fabrication, proven
mechanical advantages, and utility conservation devices provide owners and
users with a low maintenance reliable sterilizer.



2. Reliability



Industrial grade valves and high temperature gaskets prevent otherwise costly
and common

service downtime.



The vessel is tested and certified to exceed national pressure vessel standards
and carries a warranty.



3. Safety



Operator and technician safety is ensured through temperature and pressure
monitoring,relief valves, safety interlocks automatic or manual overrides.



4. Serviceability



Reduce costly maintenance downtime with easy to access consumable and
expendable components.

A maintenance program is featured in the robust easy to use PLC (Programmable
Logic Control)

system.



5. Long Life Door Gasket



Medpharm’s high temperature, air actuated door gaskets are seated into a
machined groove that

provides a close tolerance creating a less strenuous environment, extending
door gasket life
