Inconel 718 Forging Tubing Hanger

Inconel 718 UNS N07718/W.Nr. 2.4668/ Alloy 718
Inconel®718/Alloy 718 is available in wide variety of shapes and forms
including pipe, tube, fitting, flange, sheet, plate, round bar, forging stock,
flat bar, wire, hexagon. The various forms of UNS N08825 from Hengyang Piping
meet different critical standards like ASTM, ASME, DIN, EN and clients’
specification.

Inconel 718 Chemical Composition:
% Ni Cr Fe Mn C P Si S Al
Ti Mo
Min 50.0 17.0 - 0.2
0.65 2.8
Max 55.0 21.0 - 0.35 0.08 0.015 0.35 0.015 0.8
1.15 3.3
% Co Nb + Ta Bo Cu
Min 4.75
Max 1.0 5.5 0.006 0.30

Inconel 718 Physical Constants:
Density 8.22 Mg/m³
Melting Range 1260-1336 ℃

Nickel 718 Applications:
Springs, fasteners
Gas turbine engine parts
Cryogenic tanks
Firearms production
Oil and Gas

Available Products and Specifications:
Pipe & Tube ASTM Code Case N-253
DIN 17751
Rod, Bar, Wire, Forging Stock and Flange ASTM B 637 /ASME SB 637
ISO 9723
ISO 9724
DIN 17752-17754
Plate, Sheet and Strip ASTM B 670/ASME SB670
ASTM B906/ASME SB906
ISO 6208
DIN 17750

Click to Enlarge
