Instek GPT-9503: 8-Channel Hipot Tester

Features and Specifications: Instek GPT-9503 Hipot Tester, 8 Channel
Scanner, AC/DC/IR/C, Channel Status H-X, GPT-9500 Series.

sell by UMIATI Calibration


Product Overview:

The Instek GPT-9503 Hipot Tester is a versatile and powerful testing
solution designed to meet the demanding requirements of electrical safety
testing. With its 8-channel scanner and comprehensive range of test
capabilities, the GPT-9503 enables efficient and accurate testing of a wide
variety of electrical products.

Features:

8-channel scanner for simultaneous testing of multiple devices
AC, DC, IR, and C test modes
Channel status H-X for quick identification of failed channels
High voltage output up to 5kV AC/DC
Insulation resistance measurement up to 100GΩ
Capacitance measurement up to 100μF
Leakage current measurement up to 10mA
Built-in safety features for operator protection
Intuitive user interface for ease of operation
Remote control capability via USB or Ethernet

Specifications:

Voltage Range: 0 to 5kV AC/DC
Insulation Resistance Range: 0 to 100GΩ
Capacitance Range: 0 to 100μF
Leakage Current Range: 0 to 10mA
Test Modes: AC, DC, IR, C
Channel Status: H-X
Number of Channels: 8
Safety Features: Interlock, Overvoltage Protection, Overcurrent Protection

What’s in the Box:

GPT-9503 Hipot Tester
8-channel scanner
Test leads
Calibration certificate
User manual

Minimum Order: 1 pieces
