KRD16 HIGH IMPACT SHOCK TEST SYSTEM

KRD16 series shock test system is a standard testing machine stipulated by the
high impact shock test method and meets MIL-S-901D standard which covers shock
testing requirements for shipboard systems, equipment, machinery, and
structures. The high-impact shock test system is designed to verify the ability
of shipboard installations to withstand shock loadings which may be incurred
during wartime service due to the effects of underwater explosions, bump
impacts, close range shots, air explosions, train coupling loads, etc. It can
not only perform shock assessment tests on ship equipment in accordance with
military standard requirements but also can be used to test and study the shock
performance of various shock absorbers and structures. It played an important
role in improving the shock resistance of ship equipment.

FEATURES OF KRD16 HIGH ENERGY SHOCK TEST SYSTEM

CME provides lightweight & medium weight high impact shock test systems in
accordance with one of the following test categories, as specified.

Lightweight. The lightweight test is a test performed on the lightweight shock
machine. The weight of the specimen including the fixture to attach it to the
test machine shall be less than 250kg (550 pounds).

Medium weight. The medium-weight test is a test performed on the medium-weight
shock machine. The weight of the test item including the fixture to attach it
to the test machine shall be less than 3357kg (7,400 pounds).
TECHNICAL SPECIFICATIONS OF KRD16 HIGH impact testing equipment.

Model KRD16-1 KRD16-2
Parameters Lightweight Medium weight
Max Load (kg) 200 3000（Including fixtures≤3400）

Pendulum Mass (kg) 181 1342

Shock Form Preset energy automatic completion
Drop Hammer Height (mm) 0-1500 0-1870

Work Table Size (mm) 4A (Flat plate) 860×570 1520×1520
4C-Ⅰ (Angle plate) 670×300
4C-Ⅱ (Angle plate) 670×300
4C-Ⅲ (Angle plate) 670×550
Overall Dimension (mm) 4800×1400×4400 3650×3300×3200
Weight(kg) 3500 15000
Power AC380V±10％50Hz 3kW AC380V±10％50Hz 20kW
Working Environment Temperature range: 0～40℃, humidity≤80% (no condense)

Standards MIL-S-901D MIL-STD-202

TABLE OF KRD16 HIGH IMPACT SHOCK TEST SYSTEM
The lifting mechanism is used to raise a heavy hammer to a predetermined height
and then make it fall freely, and hit the cutting board on which the specimen
is installed, so that the specimen bears a complex shock load, thereby
determining the specimen's ability to withstand shock.

The lifting system is composed of an electric-reduction unit, high-strength
chain, hook, rotating arm, vertical guide track, vertical limit lever, swing
hammer angle indicator plate, etc.

Two shock hammers (horizontal hammer and vertical hammer) that can move in
different directions enable the equipment to easily realize three-directional
shock motion.
