LED Downlight DTA Series custom LED Downlight for Hotels

LED Downlight DTA Series custom LED Downlight for Hotels Black LED Downlight
manufacturer
Model: JST-DTA
Wattage: 10W-60W
LED Chip: Citizen/Cree/Epistar
Driver Brand: OSRAM/Philips/Lifud
RA: ＞90
Finish Color: White/Black/Customized
Beam Angle: 15°/24°/36°/60°
Diameter: 90mm-260mm
Cutout: 80mm-230mm
dimmable LED Downlight Description
The glareless led downlight we design to use orginal high qualtiy CITIZEN/CREE
led chip.
Design with two reflector cups, mirror-finish/sand-blast reflector.
Pure aluminum heatsink make power min10W max60W
LED Downlight Advantages
1. High Ra>90, high efficiency,high luminosisy, SDCM<3, make surroundings of
high-quality illumination
2. Glare-fee design, perfect light spot with precise cast.
3. Easy to installation.
4. Aluminum alloy housing, ensure high-end and gorgeous product with beautiful
design
Specification
Model Power CRI CCT PF Current Input Voltage Beam Angle
Dimension Cutout
JST-DTA 10W >80/90 2700K-5000K >0.65 0.25A AC220-240V
15°/24°/36°/60° D95*H75mm 80mm
JST-DTA 15W >80/90 2700K-5000K >0.90 0.35A AC220-240V
15°/24°/36°/60° D105*H80mm 90mm
JST-DTA 20W >80/90 2700K-5000K >0.90 0.50A AC220-240V
15°/24°/36°/60° D140*H130mm 120mm
JST-DTA 30W >80/90 2700K-5000K >0.90 0.75A AC220-240V
15°/24°/36°/60° D180*H155mm 150mm
JST-DTA 40W >80/90 2700K-5000K >0.90 1.00A AC220-240V
15°/24°/36°/60° D230*H193mm 200mm
JST-DTA 50W >80/90 2700K-5000K >0.90 1.25A AC220-240V
15°/24°/36°/60° D260*H210mm 230mm
JST-DTA 60W >80/90 2700K-5000K >0.90 1.50A AC220-240V
15°/24°/36°/60° D260*H225mm 230mm

Application
Fashion stores, Stations, Hotels, Offices, Shopping malls, Clubs, Supermarkets
etc.

Our products such as customized LED downlight, LED track light and LED grille
downlight have various certificates, such as CE, ROHS, SAA, CB, TUV ect.
For more information on LED lighting, click here.
https://www.jarstar-tech.com/

Minimum Order: 100 pieces
