Linux Apple CarPlay

● Linux System Car Stereos
● Apple CarPlay with License and Android Auto Function
● Support Your Own Brand with Apple License
● Panasonic MCU

SPECIFICATIONS
OS  Linux 3.4.5
CPU  SPHE 8368-C ARM Cortex-A9 single core
RAM  512M
Flansh  512M
MCU MN101AF68G (Panasonic）
Wired Phone Link Carplay / Android Auto
LCD Screen  1024*600 IPS
Touch Screen   G+G  (2.5D)
TFT drive IC  SPHE 8368-C（bulit-in)
Amplifer IC  TDA 7388
Radio IC  TEF 6851
 Buletooth IC  SPHE 888  V4.1
Video encoder  HD(720p,1080i,1080p)
Video input  One way reversing CVBS input + one way rear video input
Audio input  AUX
Video output  Two way rear video output
Audio output  Line out 4ch Subwoofer 2ch
USB interface  USB1(CP&AA); USB2
Multi media Parameters
Music format  MP3、WMA、AAC、WAVE,FLAC,APE,OGG,RA
Video format  MKV,AVI,MOV,MP4,3GP,MPEG, DAT,VOB,WMV,FLV,RMVB,RM,TS,TRP,M2TS
Picture format JPG/BMP/JEPG/GIF/PNG
Radio Parameters
frequency range FM：87.5MHz-108.0MHz,  AM:522KHZ-1622KHZ
Radio storage station  FM/AM
Radio area South America
Working voltage and memory current parameters
workin , g voltage          9V～16V
working temperature      一20℃一70℃
Memory current     < 5MA
Power amplifier parameters
Test voltage  14.4V
Maximum output power    4*25W
