LXLZ paper pulp pump

Type No. model Ranges NPSHr Speed Efficiency motor
model-power Pulp Impeller Dia.
n (%) (%)
(mm)
flow rate (m3/h) Head (m) (m) (r/min)
Concentration
A 1 80LXLZ-50-6 30-60 7-5 2.5 1420 68 Y100L1-2.2
4-6 156
B 1 80LXLZ-60-12 35-70 12-14 2.5 1440 62 Y112M-4 4-
6 210
2 80LXLZ-65-15 40-80 16-14 2.5 1440 62 Y132S-5.5
4-6 225
C 1 80LXLZ-50-20 30-60 23-21 6 1440 60 Y132S-5.5
4-6 258
2 80LXLZ-55-25 35-70 26-24 6 1440 60 Y132M-7.5
4-6 285
D 1 80LXLZ-60-35 35-70 37-33 6 1460 60 Y160M-11
4-6 323
2 80LXLZ-70-40 40-80 41-37 6 1460 60 Y160L-15
4-6 340
3 80LXLZ-80-45 55-100 44-40 6 1460 60 Y180M-18.5
4-6 353
E 1 100LXLZ-90-18 55-110 19-17 6 1440 70 Y132M-7.5
4-6 242
2 100LXLZ-110-20 65-130 23-21 6 1460 72 Y160M-11
4-6 258
F 1 100LXLZ-80-20 50-100 21-19 6 1440 68 Y132M-7.5
4-6 258
2 100LXLZ-80-25 50-100 29-25 6 1460 68 Y160M-11
4-6 285
G 1 100LXLZ-70-30 40-80 32-28 6 1460 60 Y160M-11
4-6 293
2 100LXLZ-80-35 50-100 37-33 6 1460 60 Y160L-15
4-6 320
3 100LXLZ-90-40 55-110 43-37 6 1470 60 Y180M-18.5
4-6 340
H 1 100LXLZ-150-16 90-180 19-17 6 970 68 Y180L-15
4-6 258
2 100LXLZ-160-30 95-190 32-28 6 1470 68 Y180L-22
4-6 310
3 100LXLZ-180-35 110-220 37-32 6 1470 68 Y200L-30
4-6 330
4 100LXLZ-200-40 120-240 43-37 6 1480 68 Y225S-37
4-6 350
5 100LXLZ-130-11 80-160 12-9 6 970 65 Y160M-7.5
4-6 300
K 1 100LXLZ-100-22 60-120 23-21 6 970 60 Y160M-11
4-6 385
2 100LXLZ-130-45 80-160 49-43 6 1470 60 Y200L-30
4-6 365
3 100LXLZ-140-50 85-170 55-48 6 1480 60 Y225S-37
4-6 390
4 100LXLZ-200-55 120-240 58-51 6 1480 60 Y250M-55
4-6 399
M 1 150LXLZ-160-15 95-190 12-15 6 970 75 Y160L-11
4-6 320
2 150LXLZ-200-25  120-240 25.5-22.5 6 1470 75
Y180L-22 4-6 290
3 150LXLZ-220-30 130-260 32-28 6 1470 75 Y200L-30
4-6 310
4 150LXLZ-200-20 120-240 21.5-18.5 6 1470 75
Y180M-18.5 4-6 275
5 150LXLZ-300-25 180-360 26.5-23 6 1470 75 Y200L-30
4-6 310
N 1 150LXLZ-200-14 120-240 11-13 5 970 70 Y160L-11
4-6 318
2 150LXLZ-240-14 145-290 11-14 5 970 70 Y180L-15
4-6 323
3 150LXLZ-210-16 125-250 15-13 5 970 70 Y180L-15
4-6 340
4 150LXLZ-260-16 155-310 15-13 5 970 70 Y200L1-
18.5 4-6 340
5 150LXLZ-300-30 180-360 29.5-26 5 1480 72 Y225S-37
4-6 318
6 150LXLZ-370-30 220-440 29.5-26 5 1480 72 Y225M-45
4-6 323
7 150LXLZ-320-35 190-380 36-32 5 1480 72 Y225M-45
4-6 340
8 150LXLZ-400-35 240-480 34-29 5 1480 72 Y250M-55
4-6 340
P 1 125LXLZ-130-38 80-160 40-35.5 6 1470 68 Y180L-22
4-6 340
2 125LXLZ-120-32 70-140 34-29 6 1470 68 Y180M-18.5
4-6 310
3 125LXLZ-90-17 55-110 18-15.5 6 970 68 Y160M-7.5
4-6 340
R 1 150LXLZ-300-15 180-360 16-14 5 970 75 Y200L1-
18.5 4-6 350
2 150LXLZ-280-12 170-340 11-13 5 970 75 Y180L-15
4-6 315
3 150LXLZ-430-32 260-520 34-29 5 1480 75 Y250M-55
4-6 340
4 150LXLZ-400-28 240-480 30-25 5 1480 75 Y225M-45
4-6 315
5 150LXLZ-340-25 210-430 27-20 5 1480 75 Y225S-37
4-6 300
6 150LXLZ-360-36 215-430 39-32 5 1480 75 Y250M-55
4-6 350
Q 1 150LXLZ-370-14 220-440 15-13 5 970 77 Y200L2-22
4-6 350
2 150LXLZ-350-12 210-420 11-13 5 970 77 Y200L1-
18.5 4-6 335
3 150LXLZ-570-34 340-680 35-30 5 1480 77 Y280S-75
4-6 350
4 150LXLZ-500-27 310-620 28-24 5 1480 77 Y250M-55
4-6 316
S 1 250LXLZ-800-25 480-960 26.5-23 5 1480 76 Y280M-90
4-6 330
2 250LXLZ-500-10 300-600 11-9 5 970 76 Y200L2-22
4-6 320
T 1 200LXLZ-500-43 300-600 44-40 5 1480 75 Y280M-90
4-6 384
2 200LXLZ-460-37 280-550 39-34 5 1480 72 Y280S-75
4-6 356
U 1 200LXLZ-600-14 360-720 12-15 5 1480 76 Y225S-37
4-6 260
2 200LXLZ-400-6 240-480 7-5 5 970 76 Y160L-11
4-6 260
V 1 200LXLZ-250-5 150-300 6-4 5 970 76 Y132M2-5.5
4-6 233
W 1 150LXLZ-130-5 80-160 6-4 5 970 76 Y132S-3 4-
6 228
YA 1 250LXLZ-1000-32 700-1150 34-28 1.5 1480 75
Y315M-132 4-6 353
2 250LXLZ-935-28 655-1080 30-24 1.5 1480 75
Y315S-110 4-6 330
3 250LXLZ-660-14 460-760 10-15 1.5 980 75 Y280S-45
4-6 353
4 250LXLZ-620-12 435-715 8-13 1.5 980 75 Y250M-37
4-6 330
YB 1 250LXLZ-1000-50 700-1150 52-48 1.5 1480 78
Y355M1-220 4-6 426
2 250LXLZ-950-45 665-1100 47-42 1.5 1480 78
Y315L2-185 4-6 405
3 250LXLZ-900-40 630-1035 42-38 1.5 1480 78
Y315L1-160 4-6 384
4 250LXLZ-850-36 600-980 38-33 1.5 1480 78 Y315M-132
4-6 362
5 250LXLZ-660-22 460-760 24-20 1.5 980 78 Y315S-75
4-6 426
6 250LXLZ-630-20 440-730 21-17 1.5 980 78 Y280M-55
4-6 405
7 250LXLZ-600-18 420-690 19-15 1.5 980 78 Y280S-45
4-6 384
YC 1 300LXLZ-1300-32 910-1500 34-30 1.5 1480 78
Y315L2-185 4-6 370
2 300LXLZ-1200-29 840-1380 31-27 1.5 1480 78
Y315L1-160 4-6 350
3 300LXLZ-1150-26 800-1320 28-24 1.5 1480 78
Y315M-132 4-6 335
4 300LXLZ-860-14 600-990 12-15 1.5 980 78 Y280M-55
4-6 370
5 300LXLZ-820-13 575-940 11-14 1.5 980 78 Y280S-45
4-6 350
6 300LXLZ-780-11 545-900 12-9 1.5 980 78 Y250M-37
4-6 335
YD 1 300LXLZ-1300-50 910-1500 52-48 1.5 1480 76
Y355L1-280 4-6 424
2 300LXLZ-1200-42 840-1380 44-40 1.5 1480 76
Y355M1-220 4-6 400
3 300LXLZ-1100-36 770-1270 38-33 1.5 1480 76
Y315L1-185 4-6 370
4 300LXLZ-860-22 600-990 24-20 1.5 980 76 Y315M-90
4-6 424
5 300LXLZ-800-18 560-920 19-16 1.5 980 76 Y315S-74
4-6 400
6 300LXLZ-730-16 510-840 17-14 1.5 980 76 Y280M-55
4-6 370
YE 1 350LXLZ-1600-32 1120-1840 34-30 3.5 980 79
Y355L1-220 4-6 528
2 350LXLZ-1500-28 1050-1725 30-26 3.5 980 79
Y355M2-185 4-6 495
3 350LXLZ-1400-25 980-1610 27-23 3.5 980 79
Y355M1-160 4-6 467
4 350LXLZ-1200-18 840-1380 20-16 3.5 740 79
Y315L2-110 4-6 528
YF 1 400LXLZ-2000-32 1400-2300 34-30 2.5 980 80
JS2-400M3-280 4-6 538
2 400LXLZ-1840-27 1290-2110 29-25 2.5 980 80
Y355L1-220 4-6 495
3 400LXLZ-1740-24 1220-2000 26-22 2.5 980 80
Y355M2-185 4-6 466
4 400LXLZ-1510-18 1060-1740 20-16 2.5 740 80
Y355M2-132 4-6 538
YG 1 200LXLZ-500-70 300-600 73-66 5 1480 72 Y315L1-160
4-6 487
2 200LXLZ-460-60 276-552 62-56 5 1480 72 Y315M-132
4-6 450
3 200LXLZ-425-50 255-510 53-46 5 1480 70 Y315S-110
4-6 412

Minimum Order: 1 sets
