MODEL: P48272J43C_X02 4.3 Inches, 480xRGBx272, 65K Colors

Proculus Technologies is the leading TFT display supplier and TFT display
manufacturer in the industry of embedded devices, focusing on All-in-one TFT
LCDs including UARTs and Android Solutions.

Features of 4.3 Inch LCD 480*272 Module 4.3 inch tft lcd Module
Support wide range of power supply：Default is 6~35V, use jumper to choose
4.5~5.5V;
Support RS232/TTL/CMOS, the max baud rate is 921600bps;
Support audio and video;
Support hardware JPG decoding which makes storage more efficient and display
quicker;
Support offline batch download through USB Flash Drive, which improves
download efficiency and reduce requirements for operators;
Support backlight brightness adjustment and automatic standby screen saver
function;
Support multi-language font library, picture, TWO-DIMENSIONAL code display;
Support number and English input, customizable keyboard interface;
Support 90 degrees, 180 degrees, 270 degrees screen rotation, adjustable
visual angle;
Easy-to-use UnicView GUIs Development, no coding skills required;
Instant operation when power on without system load time;
Excellent electromagnetic compatibility characteristics.

Specifications of TFT 4.3 Inch 480*272 LCD Module
Display
Color 65K (65536) colors，16 bit color 5R6G5B
ACTIVE AREA / View Area 95.0mm(width)×53.9mm(height)/97.5 mm(width)×56.4
mm(height)
Resolution 480*272，90° rotated display (272*480)
Backlight /Lifecycle/Brightness LED/20,000 HOURS/ 250 cd/m²/（64 level
adjustment）
Working Temperature -20~+70℃/-30~+85℃
Voltage & Current
Item Condition Min. Typ. Max. Unit
Power Voltage - 5.0 5.5 V
Operation Current VIN = 5V, Backlight on - 450 - mA
VIN = 5V, Backlight off - 260 - mA
Recommended Power Supply: 5V 1A DC
Reliability Test
Item Condition Min. Typ. Max. Unit
Working Temperature 　60%RH at 5V voltage -20 25 70 ℃
Storage Temperature - -30 25 85 ℃
Working Humidity 25℃ 10% 60% 90% RH
Protective Paint - - None - -
Aging Test - - 8 - H
Interface
Item Condition Min. Typ. Max. Unit
Baud Rate Standard 1200 115200 921600 bps
User-Defined 1200 - 921600 bps
Output Voltage
（TXD、BUSY） Output 1,Iout=1mA 3.0 3.2 - V
Output 0,Iout=-1mA - 0.1 0.2 V
Input Voltage
（RXD） Input 1,Iin=1mA 2.0 3.3 15.0 V
Input 0,Iin=-1mA -15.0 0.0 0.3 V
Interface Mode is determined by Jumper6: ON = 8N1, 3.3V TTL/CMOS; OFF =
8N1, RS232
Socket HY2.0-8P/10pin,1.0mm FFC
USB None
SD slot Yes (SD/SDHC, FAT32 file format)
Memory
Item Parameter Min Typ. Max Unit
Flash Space of Font - 32 - MB
Picture Storage (128MB) - - 365 Pcs
Picture Storage (256MB) - - 215 Pcs
Picture Storage (1GB) - - 932 Pcs
User’s Storage 0 - 32 MB
Peripherals
Buzzer Yes
RTC Yes
Resistive touch screen Yes
SD Card Yes
Model number
P48272J43C_N02 No Touch
P48272J43C_T02 Resistive Touch
P48272J43C_P02 Pcap Touch
Packaging and physical dimensions

Parameter Data
Dimensions 121.9(width) ×74.4(height) ×12.6(thickness without TP) /
14.1(thickness with TP) mm
Net weight of single piece TBD
Weight of whole case TBD
Packing box size TBD
Packing specification 120 pieces /box
