MTDC48-102AAB-27A18 DC Jack Connector

This product is a high-performance DC power socket connector, designed for
electronic devices requiring high-current transmission. It features high-
temperature-resistant materials and a multi-terminal design, supporting an
electrical rating of 20V/7A. With excellent durability and environmental
adaptability. Its compact structure and plating process ensure stable signal
transmission, meeting the demands of industrial, consumer electronics, and
automotive applications for highly reliable power interfaces.
DC Jack Connectors Features
High Current Capacity: Supports a rated current of 7A, meeting the power needs
of high-power devices.
Strong Environmental Resistance: Operating temperature range of -25℃ to +70℃,
suitable for harsh conditions.
Long Lifespan Design: Passed 5,000 insertion/extraction durability tests,
ensuring long-term stability.
Safety Protection: Minimum insulation resistance of 100MΩ, withstands 500V AC,
ensuring electrical safety.
Compact Layout: Multi-terminal integrated design, ideal for high-density PCB
installations.
Argument
Material of Main Part/Color PA9T/ Black
Number of Contacts 2 Pin
Rated Current 7.0A
Rated Voltage 20V
Contact Resistance 30 MAX.
Insulation Resistance 100 MIN.
Insertion Force 3N
Withdrawal Force 30N
Service Life 5000Times
Operating Temperature -25℃ ~ +75℃
