Overview of 3D 5-axis Laser Cutting Machine For Sale

GOLDEN LASER is one of professional tube laser cutting machine manufacturers.
We provide Smart Laser Tube Cutting Machine, Round Tube Laser Cutting Machine,
laser tube cutting machine, laser cutting machine for tube and so on. Want to
know more？Please contact us.

As one of the best 3d laser cutting machine suppliers, Golden laser has a 3D 5
axis laser cutting machine for sale that can process bevel cutting up to 45
degrees, making seamless splicing easier! Contact us and get a 3d cutting
machine price!
Application of 3d pipe cutting machine

Fitness equipment industry:
The bevel cutting of the 5-axis 3d tube cutting can significantly improve the
splicing defects of the fitness equipment pipe fittings, so that the welding
quality is better and the product surface is more beautiful which benefits from
3D pipe cutting machines.

Automobile pipe fittings:
Through the beveled pipe fittings, there is no gap in splicing, and the sealing
performance of the pipe fittings can be ensured after welding the CNC 3D 5-axis
laser cutting machine, which is very important for the internal oil and gas
pipelines of automobiles.

Pipe processing industry:
Compared with the traditional pipe cutting machine, the 3D 5-axis fiber laser
pipe cutting machine has a more outstanding processing capacity and a more
broad cutting range with its improved three-dimensional cutting ability.
Therefore, it is more advantageous to choose a three-dimensional five-axis
laser pipe cutting machine in the metal pipe processing industry.

Technical Data of 3D 5-axis Laser Tube Cutting Machine
Model name P2060A-3D; P3080A-3D
Workpiece length 0-6000mm; 0-8000mm
Tube diameter range 20-200mm; 20-300mm
Type of tube Round tube, square tube, rectangular tube, oval tube, channel
steel, I-beam, profile, etc.
Single tube bearing weight 25kg/m
Laser source IPG/ nLIGHT/ Raycus fiber laser generator
Laser power 1500W-6000W
Positioning accuracy ±0.03mm
Loading size 800mm*800mm*6000mm; 800mm*800mm*8000mm
Auto feeder maximum weight 2.5T


Capacities
Material 1000W 1500W 2000W 2500W 3000W 4000W
Carbon steel 6 10 12 14 16 20
Stainless steel 4 6 8 10 10 12
Galvanized steel 3 5 6 8 8 10
Aluminum 3 4 5 6 6 10
Brass 2 3 4 5 5 8
Copper 1 2 2 3 3 4

Highlights Of 3D 5-axis Laser Tube Cutting Machine
Bevel Cutting
The maximum angle of the swing angle axis is ±160°; the maximum operating
speed is 170m/min. The bevel cutting option enables high-quality bevel cuts of
up to 45°.
● Make it easier to cut irregular tubes, profiles and enable cutting
workpieces to be seamlessly spliced.

Rapid Cutting
The pipe does not need to be moved when cutting the contour with a small
figure, only the cutting head swings for rapid cutting.
● This is a significant productivity advantage, especially in thinner
materials.

Automatic Feeding
Realize batch automatic feeding of round pipes, square pipes and rectangular
pipes, which can save labor cost and improve efficiency.

Floating Support System
When cutting, the floating support device will automatically adapt to changes
in pipe rotation without interrupting the production cycle.
● More stable and high efficiency.

Pneumatic Chuck
High-speed pneumatic chuck, the maximum rotation speed is 120r/min. Thanks to
the self-adaptive adjustment of the clamping force, the operation is more
intelligent and simplified.
● Time-saving and increasing productivity.

Welded Machine Bed
The maximum thickness of the welded plate of the machine bed is 25 mm, and the
maximum weight is 7 tons, which is stable and not easily deformed.
● Longer serviceable life, more stable, anti-shocking, and accurate.

Optional Automatic Slag Removal
Optional Automatic Slag Removal: Keep the inner wall is clean and smooth.
● Improve the quality of the finished products.

Finished Products of 3D 5-axis Laser Metal Cutting Machine For Sale

Minimum Order: 100 sets
