Overview of Finished Parts Tube Laser Cutting Machine

GOLDEN LASER is one of professional tube laser cutting machine manufacturers.
We provide Smart Laser Tube Cutting Machine, Round Tube Laser Cutting Machine,
tube laser cutter machine, fiber laser tube cutting machine and so on. Want to
know more？Please contact us.

Customized solutions for finished fiber laser cutting machine parts:
The cutting requirements of finished pipe fittings are different for different
products, so we need to customize professional solutions to meet customers'
needs.

Application of Finished Tube Laser Cutting Machine
Elbow and fittings cutting:
The simple laser tube cutting machine is more difficult to cut elbow fittings
due to abnormal pipe types. However, the finished tube parts cutting machine
can realize requirements of elbow and fittings through a customized clamping
device.

Metal trolley:
Only need to perform shape cutting on the surface of the tube assembly of the
metal trolley. It has the characteristics of uniform specifications and
batches, which is very suitable for using a finished tube parts laser cutting
machine.

Outdoor tent:
Generally, the tent frame adopts similar square and round pipe fittings for
casing splicing, and the positions of the pipe butt holes are uniform.
Therefore, matching two jaws to clamp both ends of the material for processing
can improve accuracy.

Technical Data Of Finished Tube Laser Cutting Machine

Model name T2000
Maximum processing length 2000mm(customizable）
Workpiece length 0-2000mm
Tube diameter range 20-100mm(customizable）
Type of tube Round tube, square tube, rectangular tube, oval tube, etc.
Single tube bearing weight 8kg/m
Laser source IPG/ nLIGHT/ Raycus
Laser power 500W-2000W
X Y axis maximum acceleration 0.8g
Repeatability ±0.03mm
Auto feeder Industrial robot (Optional)
Equipment dimensions (length × width) 3500mm*1500mm
Equipment weight 2T


Capacities
Material 1000W 1500W 2000W 2500W 3000W 4000W
Carbon steel 6 10 12 14 16 20
Stainless steel 4 6 8 10 10 12
Galvanized steel 3 5 6 8 8 10
Aluminum 3 4 5 6 6 10
Brass 2 3 4 5 5 8
Copper 1 2 2 3 3 4

Highlights of Finished Tube Laser Cutting Machine
Break Through the Traditional Cutting Method
The two ends of the formed pipe are clamped stably, which can make the speed
faster and higher precision. At the same time, use customized high-speed
special-shaped chuck and tip-mounted fiber cutting head to realize the
processing of elbows and special-shaped tubes.

Integrated in the Automated Production Line
By matching the 3D robot arm machine and auxiliary tooling, it can quickly
realize the automatic production mode of automatic feeding, clamping, cutting,
unloading and palletizing.

Samples of Finished Parts Tube Laser Cutting Machine

Minimum Order: 100 sets
