Plastic Compact Ball Valve

Technical Product Specification
Place of Origin: Made in China
Dimensions(mm)   1/2”-6”
Material:
Body: ERA Premium LEAD FREE UNPLASTICIZED Polyvinyl chloride (PVC-U）
Handle: ABS
Rubber ring: EPDM
Seal: TPE
Inside ball: PP
Color:
Body: White, dark grey, blue, brown
Handle: Black, red, blue, green
Size NPTThd./in BSPTThd./in JIS(mm) BS(mm) ANSI(mm) DIN(mm)
15mm(1/2") 14 14 22 22 21.34 20
20mm(3/4") 14 14 26 26 26.67 25
25mm(1") 11.5 11 32 34 33.4 32
32mm(1 1/4") 11.5 11 38 42 42.16 40
40mm(1 1/2") 11.5 11 48 48 48.26 50
50mm(2") 11.5 11 60 60 60.33 63
65mm(2 1/2") 8 11 76 76 73 75
80mm(3") 8 11 89 89 88.9 90
100mm(4") 8 11 114 114 114.3 110
