Polyester / PE Coating Coils

Thousands kinds of solid and metallic colors can be choose, 8-10 years warranty
in interior environment. It is including Normal PE, High weather -
durability/HDPE, Nano Oil-proof, Anti-scratch matt gloss, Shinning pearl
flower, Wrinkle/Netting, Chameleno, Anti-bacterial, Pearl,etc...

Polyester Coated Aluminum
Coated pre-painted aluminum coils can create aesthetics and design concepts,
allowing architects and builders to create eye-catching and stunning structures
as it can be adapted to any shape.
We use advanced equipment and technology to produce polyester (PE) coated
aluminum coils. Continuous roller coating to avoid color difference. In a
baking chamber at 240 degrees Celsius, polyester paint can form a solid, high-
performance protective layer on the aluminum surface to prevent corrosion and
contamination. The polyester layer thickness is 16±1μm.

Introduction to polyester (PE) coating:
It is an anti-UV paint that uses high molecular polymer as monomer and adds
alkyd resin. It can be matte or glossy depending on your needs. The dense
molecular structure makes the dot surface glossy and smooth, ensuring good
printing effects on the paper surface.

Polyester (PE) painted aluminum coil application
•Polyester PE painted aluminum coils are used to produce aluminum ceilings,
aluminum tiles, aluminum plastic panels, aluminum honeycomb panels, aluminum
insulation panels, aluminum roller shutter foam insulation slats, aluminum
gutters and downspouts, etc.
•Polyester PE coated aluminum coils are also suitable for interior decoration
and advertising boards.

Advantage
Easy maintenance
Easy to process
light weight
Colorful design
Non-toxic and safe
Excellent coating performance

What We Can Supply
1) Thickness≤0.5mm
Thickness: 0.022mm-0.5mm
Width: 800mm-1600mm
Per Coil Weights: ＜2MT
2) Thickness＞0.5mm
Thickness: 0.5mm-01.6mm
Width: ≤1600mm
Per Coil Weights: ＜5MT
Usual Alloy: 1100, 8011, 3003, 5052, others alloy: according to your
requirments.
Usual Width: 1200mm, 1240mm, 1270mm, 1520mm, 1570mm,others width: according to
your requirments.
