Prepainted Galvanized Steel Coil


General Description of Prepainted Galvanized Steel Coil
Pre-coated coil is a product obtained by chemical surface treatment (coating)
of hot-dipped galvanized steel, galvanized steel coil or aluminum, followed by
baking and curing.

the total thickness of the prepainted galvanized steel coil consists of the
thickness of the base steel -- coating -- primer -- topcoat -- protective
coating. The top coating is 10-25 microns thick and the back coating is 5-20
microns thick. The thinner the basic steel thickness, the higher the price of
PPGI steel coil, because the processing cost will be higher.
usually, the paint material is polyester (PE) and the back paint color is white
and gray. Colors can be customized according to RAL color CARDS or customer
samples. Can make special patterns, such as wood grain, flower pattern,
camouflage, brick.

PPGI Steel Coil Specification
Product name Prepainted Galvanized Steel Coil
Material CGCC, DX51D,Q195,Q235
Zinc 20-120g
Thickness 0.13-0.8 mm
Width 600-1250 mm
Color all RAL color , as client’s request
Paint top paint : 10-30mic back paint: 5-25 mic
Paints PE, SMP, HDP, PVDF
T bend < 3T
Pencil hardness >2H
Coil ID 508/610mm
Coil weight 3-8tons
Surface glossy and matt
Glossy 30%-90%
Package standard export package (Detailed picture is as follows)
Hardness soft (normal), hard, full hard(G300-G550)
HS code 721070
Country of origin China
Business type Supplier and manufacturer
Brand name Huaro

Application of Prepainted Galvanized Steel Coil
Uncoiling machine uncoiling, leveling, length fixing, the painted galvanized
steel coil is cut into the desired length and width of flat PPGI plate, and the
roll forming machine is used to process various styles of PPGI&PPGL roof board,
such as corrugated steel plate, wave tile, Roman longtile profile.

Advantages of Prepainted Galvanized Steel Coil
you can create any shape, such as curved, rectangular, oval and tubular.
Provides a variety of color range for you to choose
promote durability
provide convenient cleaning facilities
affordable maintenance
tensile properties provide sufficient strength to cover the roof, shade and
shed.

HUARUO Industrial Group Co., Ltd is a professional prepainted galvanized steel
coil manufacturers, we provide precoated gi sheet, ppgi china, steel billets,
hot rolled steel, hot rolled coil, cold rolled steel, cold rolled steel coil
and etc. Want to know more, please contact us.

Minimum Order: 3000 sets
