PTFE Gasket

PTFE Gasket
A pure ptfe gasket is a type of sealing component made from PTFE material,
which is a synthetic fluoropolymer known for its excellent chemical resistance
and low friction properties. PTFE expanded gasket, PTFE flat gaskets are
commonly used in various industries and applications where a reliable and
effective seal is required.

The Technical Indexes of PTFE Gasket China
Type Size
DN15 22*51*3
DN20 27*61*3
DN25 34*71*3
DN32 43*82*3
DN40 49*92*3
DN50 61*107*3
DN65 77*127*3
DN80 89*142*3
DN100 115*162*3
DN125 141*192*3
DN150 169*218*3
DN200 220*273*3
DN250 273*329*3
DN300 325*384*3
DN350 377*444*3
DN400 426*495*3
DN450 480*555*3
DN500 530*617*3
DN600 630*734*3
DN700 720*804*3
DN800 820*911*3
DN900 920*1011*3
DN1000 1020*1128*3

Specification of Soft PTFE Gasket and Solid PTFE Gasket
Item Data Unit
Density 2.1-2.2 g/cm³
Tensile strength 25-45 Mpa
Elongation at break 200-350 %
Compression strength 24 Mpa
Shore D hardness 50-60
Friction coefficient 0.01

As a ptfe gasket manufacturer and ptfe gasket factory, we can offer sorts of
ptfe sealing gasket, ptfe ring gasket for sale, and the ptfe gasket price is
reasonable, anything you need, please contact us.

We can also offer sorts of uhmwpe product for sale, if you are interested,
please leave us a message.

If you want to find reliable ptfe plastic manufacturers, please choose us, and
we will be your best partner.
