PX6 Customized Android

● Rock-Chip PX6 Car Multimedia
● 6-Core with CP&AA
● NXP6686 Radio IC
● TDA7851 Power Amplifier IC
● Bluetooth 5.0

6-Core
Cotex A72 1.8GHZ
NXP 6686
TDA 7851
Bluetooth 5.0

SPECIFICATIONS
OS  Android 10 System
CPU  Rockchip PX6 ,Cortex-A72+A53, 6-Core
RAM  4G    SAMSUNG DDR3
Flansh  32G/64G
GPS   SIRF III
LCD Screen  Hanstar Screen 1920*1080 IPS
Touch Screen   G+G  (2.5D)
Phone Link CarPlay / Android Auto / Mirror Link
TFT drive IC  Rockchip  PX6
Amplifer IC  TDA 7851
Radio IC  NXP 6686
Buletooth IC  GOC-MD-6202A    V5.0
Video encoder  HD(720p,1080i,1080p)
Video input  One way reversing CVBS input + one way rear video input
Audio input  AUX
Video output  Two way rear video output
Audio output  Line out 4ch Subwoofer 2ch
USB interface  USB1(CP&AA); USB2
Multi media Parameters
Music format  MP3、WMA、AAC、WAVE,FLAC,APE,OGG,RA
Video format  MKV,AVI,MOV,MP4,3GP,MPEG, DAT,VOB,WMV,FLV,RMVB,RM,TS,TRP,M2TS
Picture format JPG/BMP/JEPG/GIF/PNG
Radio Parameters
frequency range FM：87.5MHz-108.0MHz,  AM:522KHZ-1622KHZ
Radio storage station  FM/AM/RDS
Radio area  all over the world
Working voltage and memory current parameters
workin , g voltage          9V～16V
working temperature      一20℃一70℃
Memory current     < 5MA
Power amplifier parameters
Test voltage  14.4V
Maximum output power   4*45W
