Sheet metal plate-tube integrated laser cutting machine

What is a plate-tube integrated machine?
A Plate and tube integrated Fiber Laser Cutting Machine is a type of heat
exchanger that combines both plate and tube elements to improve heat transfer
efficiency. This design incorporates plates (often flat, which provide
surface area for heat exchange) and tubes (often round or finned, which allow
fluid flow).
The machine leverages the high surface area of the plates and the fluid flow
characteristics of the tubes, making it effective for transferring heat
between two fluids or phases—like gas-to-liquid, liquid-to-liquid, or gas-
to-gas. Plate-tube integrated machines are common in applications requiring
efficient heat transfer with compact size, such as in HVAC systems,
refrigeration, and industrial processing equipment.
Here’s a breakdown of Metal plate fiber laser cutting machine key components
and functions:
1.Plates: Increase the heat transfer surface area, allowing for more
efficient heat exchange.
2.Tubes: Allow fluid to flow while maintaining structural strength and
resistance to pressure.
3.Integrated Structure: Combines the properties of both designs to handle
higher pressures, accommodate various flow rates, and maintain efficiency.
laser cutting machine Product Feature：
1.Using industrial heavy-duty steel structure design and NC five-sided
machining center to ensure machine accuracy and stability.
2.Using Schneider of France electrical appliances and IGUS cable of Germany.
3.Imported servo drive system and imported decelerator are adopted, which
have fast running speed and strong stability.
4.Taiwan guideway and high precision grinding rack are used to ensure the
long-time processing accuracy of the equipment.
5.Professional laser cutting control system with complete functions and
simple operation
6.It has the characteristics of maintenance-free, energy saving and cost
reduction.
Specification:
Model CX-3015HR
Cutting Area Plate1500mm*3000mm; Rotary D220mmx L6000mm
Laser Power 3000W MAX
Servo Motor Japan FUJI X Y Axis 850W,Z 400W
Rotary Y Axis 1.3KW, A Axis1.8KW
Controller system Cypcut 3000S
Raytools BM111 automatic head
X.Y Guide Rail Taiwan KINGTEK 25/30
Rack Germany 1.5M
Operating System Windows 98, Windows XP, Vista
Interface LCD screen with USB interface
CAD Design Software Available (Optional)
Supported Format BMP. HPGL(PLT),DXF,G-CODE,DST,AI
Working Voltage AC380V/ 50HZ
Water Chiller HL3000
