SITEPRO DW 3-D ROTARY LASER

Features:

The LR 430HDV is a 3-dimensional rotary laser featuring three 360° plane
leveling system- horizontal and two 90° vertical rotating laser planes.
1/16-in at 100 feet (1.8mm at 30m) leveling accuracy
2,950 ft (900m) diameter working range with detector
Extremely high rotation speed of up to 2,000 rpm
Electronic self-leveling
Three integrated rotary head with built-in 635nm diodes
Compact, ergonomic design with single button operation
Multiple scan angles, beam positioning, and variable rotation speeds
Single axis ±4° slope
Specifications:

Leveling: Horizontal w/2x 90° Verticals
Horizontal Accuracy: ±1/16-in at 100-ft (±1.8mm at 30m)
Vertical Accuracy: ±1/8-in at 100-ft (±3mm at 30m)
Angle Accuracy: 20”
Leveling Type: Electronic Self-Leveling (±4º)
Slope/Grade: Single Axis -4º to +4º
Working Range (dia.) Without Detector: Up to 65-ft (20m)
Working Range (dia.) With Detector: Up to 2950-ft (900m)
Beam Rating: 635 nm, Class 2
Beam Color: Red
Rotation Speed: 400, 800, 2000 RPM
Scanning: 10°, 45°, 90°

Minimum Order: 1 pieces

SITEPRO DW 3-D ROTARY LASER
