Smooth Textured Perforated HDPE Geocell Gravel Grids Paver CE Certificate

PRODUCT DESCRIPTION

HDPE Smooth Textured Perforated Geocell CE Certificate Gravel Grids Paver

Product Introduction

Typical cellular confinement systems are geosynthetics made with ultrasonically
welded high-density polyethylene (HDPE) strips or novel polymeric alloy (NPA)—
and expanded on-site to form a honeycomb-like structure—and filled with sand,
soil, rock, gravel or concrete

Specifications

Index Properties Test Method Units Values
Material - - 100% Virgin HDPE
Carbon Black content ASTM D 1603 % ≥1.5
Density ASTM D 1603 g/cm3 0.935-0.965
Sheet Thickness ± 3% ASTM D 5199 mm 1.5
Seam Peel Strength USACE GL-86-19 KN/m ≥14.2
Tensile strength at Yield ASTM D 1603 KN/m ≥22
Environmental stress crack resistance ASTM D 1603 hrs ≥5000
OIT oxidation induction time ASTM D 1603 min ≥150

Type GM330 GM356 GM400 GM432 GM445 GM500 GM660 GM712
Welding Distance(mm) ± 3% 330 356 400 432 445 500
660 712
Cell Depth(mm) ± 3% 50,75,100,150,200,250
Dimensions
Expanded Cell Size (width×length) (mm) ± 3% 250 x 210 260 x 225
290 x 260 320 x 275 315 x 300 360 x 300 470 x 450
510 x 475
Expanded Cell numbers(width×length) 10 x 34 9 x 34 8 x 34 8 x 34 8 x 34
7 x 34 5 x 34 5 x 34
Expanded Section size (width×length) (m) ± 3% 2.50 x 7.14 2.34 x 7.65
2.32 x 8.84 2.56 x 9.35 2.52 x 10.2 2.52 x 11.22 2.35 x 15.3
2.55 x 16.15
Expanded Section Area (m2) ± 5% 17.85 17.9 20.5 23.94 25.7
28.74 35.95 41.18

Application

Smooth Textured Perforated HDPE Geocell Gravel Grids Paver CE Certificate 0
SOIL REINFORCEMETN
Geomax®(Geocell) is the solution to soil stabilization or soil reinforcement.
It can increase the bearing capacity of the pavement and avoid cracking of the
pavement.

♦
50% reduction in roadbed thickness
♦
70+ years service life
♦
10 times the bearing capacity

Smooth Textured Perforated HDPE Geocell Gravel Grids Paver CE Certificate 1
SLOPE PROTECTION
Geomax®(Geocell) is the obvious choice for slope protection or erosion control.
It has both good drainage effect and slope protection.

♦
Environmentally friendly
♦
Green vegetation planted on it
♦
Excellent drainage with a perforated surface

Smooth Textured Perforated HDPE Geocell Gravel Grids Paver CE Certificate 2
CHANNEL PROTECTION
Geomax®(Geocell) delivers stability and protection of channels
exposed to erosive conditions ranging from low to high flows, either
intermittent or continuous.

♦
Prevent seepage and reduce water loss
♦
Resistance to higher velocity and continuous flows.
♦
Less costly, smaller aggregate (up to 10 times) for the same protection.

Smooth Textured Perforated HDPE Geocell Gravel Grids Paver CE Certificate 3
RETAINING WALLS
Geomax®(Geocell) offers highly permeable and acts as a great number of planting
pots, allowing rainwater to infiltrate, minimizing runoff.

♦
Naturally-Vegetated, Green Retaining Wall Systems
♦25-30% installation faster than MSE block walls.
♦
No heavy equipment required.

HCNS Manufacture
Smooth Textured Perforated HDPE Geocell Gravel Grids Paver CE Certificate 4
Smooth Textured Perforated HDPE Geocell Gravel Grids Paver CE Certificate 5

Our Certificates and HDPE Geocell Testing reports

Smooth Textured Perforated HDPE Geocell Gravel Grids Paver CE Certificate 6
